toll free 800.334.5214 ACME ELECTRIC |
Selection Charts T A a n d T B S e r i e s O p e n C o r e a n d C o i l I n d u s t r i a l C o n t r o l T r a n s f o r m e r s
240 X 480 PRIMARY VOLTS — 120/240 SECONDARY VOLTS — 1Ø, 60 Hz
Approximate Dimensions (Inches)(Cm.)
VA
Rating
Catalog
Number
Output Amps
@120V A B C D E F
Approximate
Ship Weight
(Lbs.)(Kg.)
Primary Fuse
Block Part
Number
Wiring
Diagram
50 TB83210 0.42 4.13 3.00 2.70 2.50 2.30 .22 x .50 4 PL112700 J
(10.5) (7.6) (6.8) (6.4) (5.8) (0.6 x 1.3) (1.8)
100 TB83212 0.83 4.90 3.00 2.70 2.50 3.35 .22 x .50 4 PL112700 J
(12.4) (7.6) (6.8) (6.4) (8.5) (0.6 x 1.3) (1.8)
150 TB83213 1.25 4.92 3.75 3.40 3.13 2.81 .22 x .50 6 PL112701 J
(12.5) (9.5) (8.6) (8.0) (7.1) (0.6 x 1.3) (2.7)
250 TB83215 2.08 5.38 4.50 3.84 3.75 3.05 .22 x .50 9 PL112702 J
(13.7) (11.4) (9.8) (9.5) (7.7) (0.6 x 1.3) (4.1)
500 TB83218 4.17 6.06 5.25 4.47 4.06 4.06 .22 x .50 13 PL112704 J
(15.4) (13.3) (11.4) (10.3) (10.3) (0.6 x 1.3) (5.9)
750 TB83219 6.25 6.43 5.25 4.47 4.38 5.30 .31 x .50 21 PL112704 J
(16.3) (13.3) (11.4) (11.1) (13.0) (0.8 x 1.3) (9.5)
1000 TB83220 8.33 7.34 6.75 5.78 5.75 3.69 .31 x .50 24 PL112705 J
(18.6) (17.1) (14.7) (14.6) (9.4) (0.8 x 1.3) (10.9)
1500 TA83221 12.50 8.80 6.75 5.72 5.75 5.02 .31 x .50 43 PL112705 J
(22.4) (17.1) (14.5) (14.6) (12.8) (0.8 x 1.3) (19.5)
2000 TA83222 16.67 9.15 6.75 5.72 5.75 5.42 .31 x .50 48 PL112705 J
(23.2) (17.1) (14.5) (14.6) (13.8) (0.8 x 1.3) (21.8)
3000 TA83223 25.00 7.00 7.50 7.66 6.50 5.55 .41 x .81 51 PL112706 J
(17.8) (19.1) (19.5) (16.5) (14.1) (1.0 x 2.1) (23.1)
5000 TA83224 41.67 7.06 11.92 8.75 6.75 5.75 .41 x .81 90 PL112707 J
(17.9) (30.3) (22.2) (17.1) (14.6) (1.0 x 2.1) (40.8)
Add Suffix to Catalog Number Configuration
F2 Factory installed integrally mounted 2-pole primary block
F3 Factory installed integrally mounted 3-pole primary and secondary block (100 VA & larger)
F4 Factory installed 2-pole primary block and secondary fuse clips (50 & 75 VA)
Consult factory for other sizes available.
INTEGRALLY MOUNTED FUSE BLOCKS
120X240-12/24: 50-500VA (F2 Option Only)
240X480-120/115/110: 50-2000VA
