L o w V o l t a g e L i g h t i n g T r a n s f o r m e r s
112
toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comWHY LOW VOLTAGE LIGHTING?
Acme’s Low Voltage Lighting products provide a safe, long lasting, highly reliable power source; a perfect selection for
landscape applications as well as interior use.
Low voltage lighting is a creative medium with unlimited application possibilities. Low voltage lighting benefits include:
Q
Precision beam control
Q
More light intensity per watt
Q
Less radiated heat
Q
Greater efficiency
Q
Longer life
Q
Safer to use
Q
Easy installation
Q
A high return on end-user investment
Acme low voltage transformers are available in a wide range of options and models that are all UL listed for use indoors or
outdoors. See inside back cover for warranty details.
Transformers in ratings of 100 through 1000 W; Buck–Boost in .05 through 10 kVA.
Transformers have copper lead wires for hardwiring. Circuit breakers for instant reset (except pool and spa and Buck–Boost).
No fumbling with fuses. Generous wiring compartment, too!
A full fault current carrying Faraday Shield (except Buck–Boost) prevents 120 volts from reaching the 12 volt side, as required by
UL-1571 and UL-1838.
The convenient “Selection Guide” below provides you with the data you need to select the product that best meets your
requirement. Complete product selection data, dimensions and wiring diagrams are contained on the following pages. If you
need help in your selection, or if you have questions, just call technical services at 1-800-334-5214.
Transformers
Features/Options
‘T1’ Catalog Number
Buck-Boost
‘T1’ and ‘T2’ Catalog Number
1 Ratings (Watts, VA, kVA)
100 through 1000 VA
.05 through 10 kVA
2
Primary Input
120 Volts or 240 Volts
120 x 240 Volts
3
Secondary Output
12V or 24V
12V or 24V
4
Hardwired Primary
Yes
Yes
5
Overload Protection:
Primary
Auto Thermal Reset
No
Secondary
Circuit Breakers
No
6
Output Wiring
Copper
Copper
7
UL Listed
Yes
Yes
8
CSA Certified
Yes
Yes
9
Faraday Shield
Yes
No
10
Product Warranty
10 Years
10 Years
11
UL-3R Indoor/Outdoor
Enclosure
No
Yes
