164 toll free 800.334.5214 ACME ELECTRIC |
H a r d - W i r e d S u r g e P r o t e c t i v e D e v i c e s Selection Charts
HBLSDSA36
The HBLSDSA36 Type 1 SPD is designed and listed for indoor or outdoor installation and surge suppression for single-phase
three-wire 120/240 Vac 60 Hz electrical services. Two HBLSDSA36 Type 1 SPDs can be installed to provide surge
suppression on120/208V threephase four-wire services.
HBL4SA40, HBL8SA40
The HBL4SA40, ,HBL8SA40 Type 1 SPD is designed and listed for indoor or outdoor installation and surge suppression
of three-phase grounded electrical services from 120/208 Vac up to 480 Vac line to line and is used extensively in service
entrance panels to provide an efficient and economical means of surge suppression.
HBLSDSA36
VPR
Model Number Surge Current Configuration Voltage MCOV SCCR In L-N L-G L-L N-G
HBLSDSA36 36kA 1 Ø, 3-wire, back mounted 120V/240 150V 22kA 10kA 700V N/A 1200V N/A
HBL4SA40, HBL8SA40
VPR
Model Number
Modes of
Protection Surge Current per Phase Configuration Voltage MCOV SCCR In L-N L-G L-L N-G
HBL4SA40 6 40kA 3 Ø, 4-wire 208Y/120V① 180V L-N 360V L-L 200kA 10kA 700V N/A 1200V N/A
HBL8SA40 6 40kA 3 Ø, 4-wire 208Y/120V① 420V L-N 840V L-L 200kA 10kA 1500V N/A 2500V N/A
① Applicable voltages: 220Y/127V, 208Y/120V
② Applicable voltages: 480Y/277V, 415Y/240V, 400Y/230V, 380Y/220V
