toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comE l e c t r i c a l E n c l o s u r e s
UL File E64791
CSA File LL66078
Industry Standards
UL 508, Types 4, 4X, 12 & 13
CSA Certified, Types 4, 4X, 12 & 13
NEMA/EEMAC Type 4, 4X, 12 & 13
Wall mounting brackets required to
maintain UL /CSA external mounting
requirements.
N412 — CSSST ULTIMATE SERIES ENCLOSURES NEMA 4X STAINLESS SLOPE TOP SINGLE DOOR
Catalog Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Back Panel Catalog Number*
White 304 SS G
”
Back Panel Size A&B
(Inches)(Cm.)
N412161208CSSST
16.0
(40.6)
12.00
(50.8)
8.0
(20.3)
NP1612
NP1612SSC
NP1612G
14.2x10.2
(36.1x25.9)
N412161608CSSST
16.0
(40.6)
12.00
(50.8)
8.0
(20.3)
NP1616
NP1616SSC
NP1616G
14.2x14.2
(36.1x36.1)
N412201608CSSST
20.0
(50.8)
16.0
(40.6)
8.0
(20.3)
NP2016
NP2016SSC
NP2016G
18.2x14.2
(46.2x36.1)
N412201612CSSST
20.0
(50.8)
16.0
(40.6)
12.0
(30.5)
NP2016
NP2016SSC
NP2016G
18.2x14.2
(46.2x36.1)
N412202008CSSST
20.0
(50.8)
20.0
(50.8)
8.0
(20.3)
NP2020
NP2020SSC
NP2020G
18.2x18.2
(46.2x46.2)
N412202012CSSST
20.0
(50.8)
20.0
(50.8)
12.00
(50.8)
NP2020
NP2020SSC
NP2020G
18.2x18.2
(46.2x46.2)
N412242008CSSST
24.0
(61.0)
20.0
(50.8)
8.0
(20.3)
NP2420
NP2420SSC
NP2420G
22.2x18.2
(56.4x46.2)
N412242408CSSST
24.0
(61.0)
24.0
(61.0)
8.0
(20.3)
NP2424
NP2424SSC
NP2424G
22.2x22.2
(56.4x56.4)
N412242412CSSST
24.0
(61.0)
24.0
(61.0)
12.0
(30.5)
NP2424
NP2424SSC
NP2424G
22.2x22.2
(56.4x56.4)
N412302408CSSST
30.0
(76.2)
24.0
(61.0)
8.0
(20.3)
NP3024
NP3024SSC
NP3024G
28.2x22.2
(71.6x56.4)
N412302412CSSST
30.0
(76.2)
24.0
(61.0)
12.0
(30.5)
NP3024
NP3024SSC
NP3024G
28.2x22.2
(71.6x56.4)
N412303008CSSST
30.0
(76.2)
30.0
(76.2)
8.0
(20.3)
NP3030
NP3030SSC
NP3030G
28.2x28.2
(71.6x71.6)
N412363008CSSST
36.0
(91.4)
30.0
(76.2)
8.0
(20.3)
NP3630
NP3630SSC
NP3630G
34.2x28.2
(86.9x71.6)
N412363012CSSST
36.0
(91.4)
30.0
(76.2)
12.00
(50.8)
NP3630
NP3630SSC
NP3630G
34.2x28.2
(86.9x71.6)
N412363016CSSST
36.0
(91.4)
30.0
(76.2)
16.0
(40.6)
NP3630
NP3630SSC
NP3630G
34.2x28.2
(86.9x71.6)
N412363612CSSST
36.0
(91.4)
36.0
(91.4)
12.00
(50.8)
NP3636
NP3636SSC NP3636G
34.2x34.2
(86.9x86.9)
N412483616CSSST**
48.0
(121.9)
36.0
(91.4)
16.0
(40.6)
NP4836
NP4836SSC
NP4836G
46.2x34.2
(117.3x86.9)
N412603616CSSST**
60.0
(152.4)
36.0
(91.4)
16.0
(40.6)
NP6036
NP6036SSC
NP6036G
58.2x34.2
(147.8x86.9)
*Back panels must be ordered separately.
**Enclosures are supplied with closed cell neoprene gasket (not foam-in-place).
