E l e c t r i c a l E n c l o s u r e s
190 toll free 800.334.5214 ACME ELECTRIC |
N412-SSC ULTIMATE SERIES SINGLE DOOR STAINLESS ENCLOSURES (CONT.)
Catalog Number
304 SS 316L SS
Body/Door
Steel Gauge
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Back Panel Catalog Number*
White 304 SS G ”
Back Panel
Size A&B
(Inches)(Cm.)
C
(Inches)
(Cm.)
E
N412242008SSC N412242008SSAC 14/14 24.0
(61.0)
20.0
(50.8)
8.0
(20.3) NP2420C NP2420SSC NP2420CG 22.2x18.2(56.4x46.2)
12.0
(30.5) —
N412242408SSC N412242408SSAC 14/14 24.0
(61.0)
24.0
(61.0)
8.0
(20.3) NP2424C NP2424SSC NP2424CG 22.2x22.2(56.4x56.4)
4.0
(10.2)
16.0
(40.6)
N412302408SSC N412302408SSAC 14/14 30.0
(76.2)
24.0
(61.0)
8.0
(20.3) NP3024C NP3024SSC NP3024CG 28.2x22.2(71.6x56.4)
4.0
(10.2)
22.0
(55.9)
N412303008SSC N412303008SSAC 14/14 30.0
(76.2)
30.0
(76.2)
8.0
(20.3) NP3030C NP3030SSC NP3030CG 28.2x28.2(71.6x71.6)
4.0
(10.2)
22.0
(55.9)
N412362408SSC N412362408SSAC 14/14 36.0
(91.4)
24.0
(61.0)
8.0
(20.3) NP3624C NP3624SSC NP3624CG 34.2x22.2(86.9x56.4)
4.0
(10.2)
28.0
(71.1)
N412363008SSC N412363008SSAC 14/14 36.0
(91.4)
30.0
(76.2)
8.0
(20.3) NP3630C NP3630SSC NP3630CG 34.2x28.2(86.9x71.6)
4.0
(10.2)
28.0
(71.1)
N412161210SSC N412161210SSAC 14/14 16.0
(40.6)
12.0
(30.5)
10.0
(25.4) NP1612C NP1612SSC NP1612CG 14.2x10.2(36.1x25.9)
8.0
(20.3) —
N412161610SSC N412161610SSAC 14/14 16.0
(40.6)
16.0
(40.6)
10.0
(25.4) NP1616C NP1616SSC NP1616CG 14.2x14.2(36.1x36.1)
8.00
(20.3) —
N412162010SSC N412162010SSAC 14/14 16.0
(40.6)
20.0
(50.8)
10.0
(25.4) NP1620C NP1620SSC NP1620CG 14.2x18.2(36.1x46.7)
8.0
(20.3) —
N412201610SSC N412201610SSAC 14/14 20.0
(50.8)
16.0
(40.6)
10.0
(25.4) NP2016C NP2016SSC NP2016CG 18.2x14.2(46.7x36.1)
10.0
(25.4) —
N412202010SSC N412202010SSAC 14/14 20.0
(50.8)
20.0
(50.8)
10.0
(25.4) NP2020C NP2020SSC NP2020CG 18.2x18.2(46.7x46.7)
10.0
(25.4) —
N412241610SSC N412241610SSAC 14/14 24.0
(61.0)
16.0
(40.6)
10.0
(25.4) NP2416C NP2416SSC NP2416CG 22.2x14.2(56.4x36.1)
10.0
(25.4) —
N412242010SSC N412242010SSAC 14/14 24.0
(61.0)
20.0
(50.8)
10.0
(25.4) NP2020C NP2020SSC NP2020CG 18.2x18.2(46.7x46.7)
10.0
(25.4) —
N412242410SSC N412242410SSAC 14/14 24.0
(61.0)
24.0
(61.0)
10.0
(25.4) NP2424C NP2424SSC NP2424CG 22.2x22.2(56.9x56.9)
4.0
(10.2)
16.0
(40.6)
N412302410SSC N412302410SSAC 14/14 30.0
(76.2)
24.0
(61.0)
10.0
(25.4) NP3024C NP3024SSC NP3024CG 28.2x22.2(71.6x56.4)
4.0
(10.2)
22.0
(55.9)
N412303010SSC N412303010SSAC 14/14 30.0
(76.2)
30.0
(76.2)
10.0
(25.4) NP3030C NP3030SSC NP3030CG 28.2x28.2(71.6x71.6)
4.0
(10.2)
22.0
(55.9)
N412362410SSC N412362410SSAC 14/14 36.0
(91.4)
24.0
(61.0)
10.0
(25.4) NP3624C NP3624SSC NP3624CG 34.2x22.2(86.9x56.4)
4.0
(10.2)
28.0
(71.1)
N412363010SSC N412363010SSAC 14/14 36.0
(91.4)
30.0
(76.2)
10.0
(25.4) NP3630C NP3630SSC NP3630CG 34.2x28.2(86.9x71.6)
4.0
(10.2)
28.0
(71.1)
N412363610SSC N412363610SSAC 14/14 36.0
(91.4)
36.0
(91.4)
10.0
(25.4) NP3636C NP3636SSC NP3636CG 34.2x34.2(86.9x86.9)
4.0
(10.2)
28.0
(71.1)
N412423610SSC N412423610SSAC 14/14 42.0
(106.7)
36.0
(91.4)
10.0
(25.4) NP4236C NP4236SSC NP4236CG 40.2x34.2(102.1x86.9)
21.0
(53.3) —
N412483610SSC N412483610SSAC 14/14 48.0
(121.9)
36.0
(91.4)
10.0
(25.4) NP4836C NP4836SSC NP4836CG 46.2x34.2(117.3x86.9)
24.0
(61.0) —
N412603610SSC N412603610SSAC 14/14 60.0
(152.4)
36.0
(91.4)
10.0
(25.4) NP6036C NP6036SSC NP6036CG 58.2x34.2(147.8x86.9)
30.0
(76.2) —
N412202012SSC N412202012SSAC 14/14 20.0
(50.8)
20.0
(50.8)
12.0
(30.5) NP2020C NP2020SSC NP2020CG 18.2x18.2(46.2x46.2)
10.0
(25.4 —
N412242412SSC N412242412SSAC 14/14 24.0
(61.0)
24.0
(61.0)
12.0
(30.5) NP2424C NP2424SSC NP2424CG 22.2x22.2(56.4x56.4)
4.0
(10.2)
16.0
(40.6)
N412302412SSC N412302412SSAC 14/14 30.0
(76.2)
24.0
(61.0)
12.0
(30.5) NP3024C NP3024SSC NP3024CG 28.2x22.2(71.6x56.4)
4.0
(10.2)
22.0
(55.9)
N412362412SSC N412362412SSAC 14/14 36.0
(91.4)
24.0
(61.0)
12.0
(30.5) NP3624C NP3624SSC NP3624CG 34.2x22.2(86.9x56.4)
4.0
(10.2)
28.0
(71.1)
N412363012SSC N412363012SSAC 14/14 36.0
(91.4)
30.0
(76.2)
12.0
(30.5) NP3630C NP3630SSC NP3630CG 34.2x28.2(86.9x71.6)
4.0
(10.2)
28.0
(71.1)
