Acme’s mechanical transformer lug kits contain all of the hardware necessary to provide satisfactory transformer terminations. Lug
kits are available in sizes from 27 kVA to 660 kVA.
Acme lugs are of the dual rated single pole solderless type, made from high strength aluminum alloy. To provide the best in low
contact resistance, all lugs in these kits are plated.
Lug Kits
Kit Contains
Catalog
Number
Transformer
kVA size
Wire Range
AI or Cu
Quantity Nuts and
Bolts
Quantity
Lug 1
37 1/2 1-phase 2 -14 8 1 /4 - 20 x 3/4
8
27-45 3-phase 250 mcm - 6 4
Lug 2
50 - 75 1-phase
250 mcm - 6 12
1 /4 - 20 x 3/4 8
51 - 118 3-phase 4 - 20 x 13/4 8
Lug 3
100 -167 1-phase 250 mcm - 6 3 1 /4 - 20 x 3/4 3
145 - 300 3-phase 600 mcm - 2 22 3 /8 - 16 x 2 16
Lug 4 440 - 660 3-phase 600 mcm - 2 29 3 /8 - 16 x 2 8
Top Cover
Catalog Number Weight (Lbs.)(Kg.)
SA1701319 14 (6.4)
SA2701319 16 (7.3)
SA3701319 20 (9.1)
SA4701319 34 (15.4)
SA6701319 17 (7.7)
Weather Shields
Catalog Number Weight (Lbs.)(Kg.)
WSA1 6 (2.7)
WSA2 7 (3.2)
WSA3 8 (3.6)
WSA4 8 (3.6)
WSA5 10 (4.5)
WSA6 10 (4.5)
WSA8 7 (3.2)
WSB3 30 (13.6)
WSB4 32 (14.5)
Side Panel
Catalog Number Weight (Lbs.)(Kg.)
SA1701320 11 (5.0)
SA2701320 13 (5.9)
SA3701320 19 (8.6)
SA4701320 34 (15.4)
Front/Rear Panel
Catalog Number Weight (Lbs.)(Kg.)
SA1701321 13 (5.9)
SA2701321 15 (6.8)
SA3701321 21 (9.5)
SA4701321 35 (15.9)
SA7701321 16 (7.3)
