toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comD r i v e I s o l a t i o n T r a n s f o r m e r s a n d A C L i n e R e a c t o r s
Selection Charts
480 VOLTS, 5% Z, 60 Hz (600 VOLTS, 4% Z; 240 VOLTS, 10% Z)
Motor*
Dimensions
Mounting Dimensions
Catalog
Number
H.P.
Amp
Reactor
Amp
uH
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
A (Depth)
B (Width)
Weight
(Lbs.)(Kg.)
ALRC002TBC
①
1 2.1
2
18378
3.875 (9.8)
4.25 (10.8)
3.125 (7.9)
2.00 (5.1)
1.44 (3.7)
3 (1.4)
ALRC003TBC
①
1.5 3
3
12252
3.875 (9.8)
4.25 (10.8)
3.125 (7.9)
2.00 (5.1)
1.44 (3.7)
3 (1.4)
ALRC004TBC
①
2 3.4
4
9189
3.875 (9.8)
4.25 (10.8)
3.125 (7.9)
2.10 (5.3)
1.44 (3.7)
4 (1.8)
ALRC006TBC
①
3 4.8
6
6126
4.75 (12.1)
6.50 (16.5)
3.75 (9.5)
2.10 (5.3)
2.00 (5.1)
5 (2.3)
ALRC008TBC
①
5 7.6
8
4594
4.75 (12.1)
6.50 (16.5)
3.75 (9.5)
2.10 (5.3)
2.00 (5.1)
6 (2.7)
ALRC012TBC
①
7.5 11
12
3063
4.75 (12.1)
6.50 (16.5)
3.75 (9.5)
2.20 (5.6)
2.00 (5.1)
7 (3.2)
ALRC016TBC
①
10 14
16
2297
4.75 (12.1)
6.50 (16.5)
4.00 (10.2)
2.60 (6.6)
2.00 (5.1)
9 (4.1)
ALRC025TBC
①
15 21
25
1470
4.75 (12.1)
6.50 (16.5)
4.50 (11.4)
3.00 (7.6)
2.00 (5.1)
13 (5.9)
ALRC027TBC
①
20 27
27
1361
4.75 (12.1)
6.50 (16.5)
4.50 (11.4)
2.80 (7.1)
3.00 (7.6)
13 (5.9)
ALRC035TBC
①
25 34
35
1050
7.00 (17.8)
9.00 (22.9)
4.75 (12.1)
3.60 (9.1)
3.00 (7.6)
23 (10.4)
ALRC045TBC
①
30 40
45
817
7.00 (17.8)
9.00 (22.9)
4.75 (12.1)
3.60 (9.1)
3.00 (7.6)
23 (10.4)
ALRC055TBC
①
40 52
55
668
7.00 (17.8)
9.00 (22.9)
4.75 (12.1)
3.60 (9.1)
3.00 (7.6)
24 (10.9)
ALRC080TBC 60 77
80
459
7.00 (17.8)
9.00 (22.9)
5.75 (14.6)
4.60 (11.7)
3.60 (9.1)
34 (15.4)
ALRC110CBC 75 96
110
334
7.00 (17.8)
9.00 (22.9)
6.50 (16.5)
4.20 (10.7)
3.60 (9.1)
56 (25.4)
ALRC130CBC 100 124
130
283
7.00 (17.8)
9.00 (22.9)
6.50 (16.5)
4.20 (10.7)
3.60 (9.1)
56 (25.4)
ALRC160CBC 125 156
160
230
7.00 (17.8)
9.00 (22.9)
8.00 (20.3)
4.20 (10.7)
3.60 (9.1)
70 (31.8)
ALRC200CBC 150 180
200
184
8.50 (21.6)
10.80 (27.4)
8.25 (21.0)
5.90 (15.0)
3.60 (9.1)
76 (34.5)
ALRC250CBC 200 240
250
147
8.50 (21.6)
10.80 (27.4)
8.25 (21.0)
6.20 (15.7)
4.60 (11.7)
89 (40.4)
ALRC300CBC 250 302
300
123
10.93 (27.8)
16.50 (41.9)
8.13 (20.7)
6.20 (15.7)
4.60 (11.7)
106 (48.1)
ALRC360CBC 300 361
360
102
10.93 (27.8)
16.50 (41.9)
9.50 (24.1)
8.20 (20.8)
4.60 (11.7)
124 (56.2)
ALRC420CBC 350 414
420
88
10.93 (27.8)
16.50 (41.9)
9.50 (24.1)
8.20 (20.8)
4.60 (11.7)
124 (56.2)
ALRC480CBC 400 477
480
77
10.93 (27.8)
16.50 (41.9)
10.13 (25.7)
8.20 (20.8)
4.60 (11.7)
129 (58.5)
ALRC600CBC 500 590
600
61
10.93 (27.8)
16.50 (41.9)
10.13 (25.7)
8.20 (20.8)
7.20 (18.3)
190 (86.2)
* Motor HP and Amp rated at 480 volts.
①
CE Marked
