toll free 800.334.5214 ACME ELECTRIC |
Selection Charts D r i v e I s o l a t i o n T r a n s f o r m e r s a n d A C L i n e R e a c t o r s
kVA
Primary
460V Delta
Secondary
230Y/133
Catalog
Number
Primary
460V Delta
Secondary
460Y/266
Catalog
Number
Height}
(Inches)(Cm.)
Width}
(Inches)(Cm.)
Depth}
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Weather
Shield Dimension Drawing
7.5 DTGA72S (37) DTGB72S (34) 15.21 (38.6) 19.25 (48.9) 7.37 (18.7) 180 (81.6) W NA F
11.0 DTGA0112S DTGB0112S 18.86 (47.9) 20.30 (51.6) 9.03 (22.9) 265 (120.0) F ① NA I
14.0 DTGA0142S DTGB0142S 18.86 (47.9) 20.30 (51.6) 9.03 (22.9) 270 (123.0) F ① NA I
20.0 DTGA0202S DTGB0202S 20.77 (52.8) 20.94 (53.2) 10.18 (25.9) 435 (197.0) F ① NA I
27.0 DTGA0274S (38) DTGB0274S (35) 25.50 (64.8) 24.39 (61.9) 19.37 (49.2) 320 (145.0) F ② WSA1 E
34.0 DTGA0344S DTGB0344S 25.50 (64.8) 24.39 (61.9) 19.37 (49.2) 340 (154.0) F ② WSA1 E
40.0 DTGA0404S DTGB0404S 25.50 (64.8) 24.39 (61.9) 19.37 (49.2) 395 (179.0) F ② WSA1 E
51.0 DTGA0514S DTGB0514S 29.90 (75.9) 28.15 (71.5) 22.37 (56.8) 400 (181.0) F ② WSA2 E
63.0 DTGA0634S DTGB0634S 29.90 (75.9) 28.15 (71.5) 22.37 (56.8) 550 (250.0) F ② WSA2 E
75.0 DTGA0754S DTGB0754S 29.90 (75.9) 28.15 (71.5) 22.37 (56.8) 570 (259.0) F ② WSA2 E
93.0 DTGA0934S DTGB0934S 35.90 (91.2) 31.90 (81.0) 26.88 (68.3) 685 (311.0) F WSA3 E
118.0 DTGA01184S DTGB01184S 35.90 (91.2) 31.90 (81.0) 26.88 (68.3) 765 (347.0) F WSA3 E
145.0 DTGA01454S DTGB01454S 41.52 (105.5) 32.90 (83.6) 29.88 (75.9) 990 (449.0) F WSA4 E
175.0 DTGA01754S DTGB01754S 41.52 (105.5) 32.90 (83.6) 29.88 (75.9) 1100 (499.0) F WSA4 E
220.0 DTGA02204S DTGB02204S 41.52 (105.5) 32.90 (83.6) 29.88 (75.9) 1120 (508.0) F WSA4 E
275.0 DTGA002754S DTGB002754S 45.60 (115.8) 39.50 (100.3) 35.50 (90.2) 2090 (948.0) F WSA5 E
330.0 DTGA03304S DTGB03304S 45.60 (115.8) 39.50 (100.3) 35.50 (90.2) 2090 (948.0) F WSA5 G
440.0 DTGB04404S 57.84 (146.9) 45.50 (115.6) 41.49 (105.4) 2295 (1043.2) F WSA7 G
550.0 DTGB05504S 57.84 (146.9) 45.50 (115.6) 41.49 (105.4) 2580 (1172.7) F WSA7 G
660.0 DTGB06604S 62.84 (159.6) 54.00 (137.2) 41.49 (105.4) 3700 (1678.3) F WSA6 G
770.0 DTGB07704S 62.84 (159.6) 54.00 (137.2) 41.49 (105.4) 4044 (1838.2) F WSA6 G
880.0 DTGB008804S 62.84 (159.6) 54.00 (137.2) 41.49 (105.4) 4230 (1922.7) F WSA6 G
990.0 DTGB9902S 62.84 (159.6) 54.00 (137.2) 41.49 (105.4) 4285 (1947.7) F WSA6 G
① Optional wall mounting kits-part # PL79911,refer to page 209.
② Optional wall mounting kits-part # PL79912,refer to page 209.
} Dimensions may change and are not to be used for detailed construction purposes. Please contact the factory for certified dimensional drawings.
The number in ( )’s following the catalog number is the electrical wiring diagram number beginning on page 209.
