hubbell-acmeelectric.comD r i v e I s o l a t i o n T r a n s f o r m e r s a n d A C L i n e R e a c t o r s
Selection Charts
kVA
Primary 230V Delta
Secondary 230Y/133
Catalog Number
Height
}
(Inches)(Cm.)
Width
}
(Inches)(Cm.)
Depth
}
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Weather Shield Dimension Drawing
7.5
DTFA72S
(62)
15.21 (38.6)
19.25 (48.9)
7.37 (18.7)
180 (81.6)
W
NA
F
11.0
DTFA0112S
18.86 (48.0)
20.30 (51.6)
9.03 (22.9)
265 (120.0)
F
①
NA
I
14.0
DTFA0142S
18.86 (48.0)
20.30 (51.6)
9.03 (22.9)
265 (120.0)
F
①
NA
I
20.0
DTFA0202S
20.77 (52.8)
20.94 (53.2)
10.18 (25.9)
435 (197.0)
F
①
NA
I
27.0
DTFA0274S
(59)
25.48 (64.8)
24.39 (62.0)
19.40 (49.3)
302 (137.0)
F
②
WSA1
E
34.0
DTFA0344S
25.48 (64.8)
24.39 (62.0)
19.40 (49.3)
330 (150.0)
F
②
WSA1
E
40.0
DTFA0404S
25.48 (64.8)
24.39 (62.0)
19.40 (49.3)
370 (168.0)
F
②
WSA1
E
51.0
DTFA0514S
29.40 (74.7)
28.15 (71.5)
22.40 (56.9)
375 (170.0)
F
②
WSA2
E
63.0
DTFA0634S
29.40 (74.7)
28.15 (71.5)
22.40 (56.9)
495 (225.0)
F
②
WSA2
E
75.0
DTFA0754S
29.40 (74.7)
28.15 (71.5)
22.40 (56.9)
525 (238.0)
F
②
WSA2
E
93.0
DTFA0934S
35.40 (89.9)
31.90 (81.0)
26.90 (68.3)
685 (311.0)
F
WSA3
E
118.0
DTFA01184S
35.40 (89.9)
31.90 (81.0)
26.90 (68.3)
710 (322.0)
F
WSA3
E
145.0
DTFA01454S
41.52 (105.5)
32.90 (83.6)
29.90 (75.9)
980 (445.0)
F
WSA4
E
175.0
DTFA01754S
41.52 (105.5)
32.90 (83.6)
29.90 (75.9)
1110 (504.0)
F
WSA4
E
220.0
DTFA02204S
41.52 (105.5)
32.90 (83.6)
29.90 (75.9)
1120 (508.0)
F
WSA4
E
①
Optional wall mounting kits – part # PL 79911 refer to page 217.
②
Optional wall mounting kits – part # PL 79912 refer to page 217.
The number in ( )’s following the catalog number is the electrical wiring diagram number beginning on page 209.
