toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comSelection Charts
N o n - L i n e a r L o a d I s o l a t i o n
®
T r a n s f o r m e r s
K FACTOR 13, 115°C RISE
480 DELTA PRIMARY VOLTS –– 208Y/120 SECONDARY VOLTS –– 3Ø, 60 Hz
kVA Catalog Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Wiring Diagrams Design Figures
15 T3015K0013BK13SF
25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
366 (166.0)
F
①
22
E
30 T3030K0013BK13SF
25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
500 (226.8)
F
22
E
45 T3045K0013BK13SF
29.40 (74.7)
28.15 (71.5)
22.37 (56.8)
600 (272.0)
F
22
E
75 T3075K0013BK13SF
35.40 (89.9)
31.90 (81.0)
26.87 (68.3)
938 (425.5)
F
22
E
112 T3112K0013BK13SF 41.52 (105.4)
32.90 (83.6)
29.88 (75.9)
1213 (550.2)
F
22
E
150 T3150K0013BK13SF 41.52 (105.5)
32.90 (83.6)
29.88 (75.9)
1600 (725.8)
F
22
E
225 T3225K0013BK13SF 45.60 (115.8)
39.50 (100.3)
35.50 (90.2)
1938 (879.0)
F
22
E
Notes: All models are DOE 2016 compliant
①
Wall mounting brackets are available for these sizes, refer to page 217.
For Additional Low Temperature Rise 115° and 80° Degree Units and Copper Wound Units, Consult Factory
Non-Linear Load Isolation® Wiring Diagrams (refer to page 209)
Non-Linear Load Isolation® Design Figures (refer to page 208)
K FACTOR 4, 150°C RISE
480 DELTA PRIMARY VOLTS –– 208Y/120 SECONDARY VOLTS –– 3Ø, 60 Hz
kVA Catalog Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Wiring Diagrams
Design Figures
15.0 T3015K0013BK4S 25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
325 (147.0)
F
①
22
E
30.0 T3030K0013BK4S 25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
366 (166.0)
F
①
22
E
45.0 T3045K0013BK4S 25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
500 (226.8)
F
①
22
E
75.0 T3075K0013BK4S 29.40 (74.7)
28.15 (71.5)
22.37 (56.8)
600 (272.0)
F
22
E
112.5 T3112K0013BK4S 35.40 (89.9)
31.90 (81.0)
26.87 (68.3)
938 (425.5)
F
22
E
150.0 T3150K0013BK4S 41.52 (105.5)
32.90 (83.6)
29.88 (75.9)
1213 (550.2)
F
22
E
225.0 T3225K0013BK4S 41.52 (105.5)
32.90 (83.6)
29.88 (75.9)
1600 (725.8)
F
22
E
Notes: All models are DOE 2016 compliant
①
Wall mounting brackets are available for these sizes, refer to
refer to page 217.
