toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comN o n - L i n e a r L o a d I s o l a t i o n
®
T r a n s f o r m e r s
Selection Charts
K FACTOR 20, 150°C RISE
480 DELTA PRIMARY VOLTS –– 208Y/120 SECONDARY VOLTS –– 3Ø, 60 Hz
kVA Catalog Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Wiring
Diagrams
Design Figures
15.0 T3015K0013BK20S
25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
366 (166.0)
F
①
22
E
30.0 T3030K0013BK20S
25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
500 (226.8)
F
①
22
E
45.0 T3045K0013BK20S
29.40 (74.7)
28.15 (71.5)
22.37 (56.8)
600 (272.0)
F
22
E
75.0 T3075K0013BK20S
35.90 (91.2)
31.90 (81.0)
26.88 (68.3)
938 (425.5)
F
22
E
112.5 T3112K0013BK20S 41.52 (105.5)
32.90 (83.6)
29.88 (75.9)
1213 (550.2)
F
22
E
150.0 T3150K0013BK20S 41.52 (105.5)
32.90 (83.6)
29.88 (75.9)
1600 (725.8)
F
22
E
225.0 T3225K0013BK20S 45.60 (115.8)
39.50 (100.3)
35.50 (90.2)
1938 (879.0)
F
22
E
Notes: All models are DOE 2016 compliant
①
Wall mounting brackets are available for these sizes, refer to page 217.
K FACTOR 13, 150°C RISE
480 DELTA PRIMARY VOLTS –– 208Y/120 SECONDARY VOLTS –– 3Ø, 60 Hz
kVA Catalog Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Wiring Diagrams
Design Figures
15.0 T3015K0013BK13S 25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
366 (166.0)
F
①
22
E
30.0 T3030K0013BK13S 25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
500 (226.8)
F
①
22
E
45.0 T3045K0013BK13S 29.90 (75.9)
28.15 (71.5)
22.37 (56.8)
600 (272.0)
F
①
22
E
75.0 T3075K0013BK13S 35.90 (91.2)
31.90 (81.0)
26.88 (68.3)
938 (425.5)
F
22
E
112.5 T3112K0013BK13S 41.52 (105.5)
32.90 (83.6)
29.88 (75.9)
1213 (550.2)
F
22
E
150.0 T3150K0013BK13S 41.52 (105.5)
32.90 (83.6)
29.88 (75.9)
1600 (725.8)
F
22
E
225.0 T3225K0013BK13S 45.60 (115.8)
39.50 (100.3)
35.50 (90.2)
1938 (879.0)
F
22
E
Notes: All models are DOE 2016 compliant
①
Wall mounting brackets are available for these sizes, refer to
refer to page 217.
K FACTOR 13, 150°C RISE
208 DELTA PRIMARY VOLTS –– 208Y/120 SECONDARY VOLTS –– 3Ø, 60 Hz
kVA Catalog Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Wiring Diagrams
Design Figures
15 T3015K0064BK13S 25.50 (64.8)
24.40 (62.0)
19.37 (49.2)
366 (166.0)
F
①
61
E
30 T3030K0064BK13S 25.50 (64.8)
24.90 (62.0)
19.37 (49.2)
522 (236.8)
F
①
61
E
45 T3045K0064BK13S 29.40 (74.7)
28.15 (71.5)
22.37 (56.8)
667 (302.6)
F
①
61
E
75 T3075K0064BK13S 35.40 (89.9)
31.90 (81.0)
26.87 (68.3)
938 (425.5)
F
61
E
112 T3112K0064BK13S 41.52 (105.5)
32.90 (83.6)
29.88 (75.9)
1213 (550.2)
F
61
E
150 T3150K0064BK13S 41.52 (105.5)
32.90 (83.6)
29.88 (75.9)
1700 (771.0)
F
61
E
225 T3225K0064BK13S 45.60 (115.8)
39.50 (100.3)
35.50 (90.2)
2165 (982.0)
F
61
E
Notes: All models are DOE 2016 compliant
①
Wall mounting brackets are available for these sizes,refer to page 217.
