hubbell-acmeelectric.comSelection Charts
D r i v e I s o l a t i o n T r a n s f o r m e r s a n d A C L i n e R e a c t o r s
480 VOLTS, 3% Z, 60 Hz (600 VOLTS, 2.4% Z; 240 VOLTS, 6% Z)
Motor*
Dimensions
Mounting Dimensions
Catalog
Number
H.P.
Amp
Reactor
Amp
uH
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
A (Depth)
B (Width)
Weight
(Lbs.)(Kg.)
ALRB002TBC
①
1
2.1
2
11027
3.875 (9.8)
4.25 (10.8)
3.125 (7.90)
2.00 (5.1)
1.44 (3.7)
3 (1.4)
ALRB003TBC
①
1.5
3
3
7351
3.875 (9.8)
4.25 (10.8)
3.125 (7.90)
2.00 (5.1)
1.44 (3.7)
3 (1.4)
ALRB004TBC
①
2
3.4
4
5513
3.875 (9.8)
4.25 (10.8)
3.125 (7.90)
2.00 (5.1)
1.44 (3.7)
3 (1.4)
ALRB006TBC
①
3
4.8
6
3676
3.875 (9.8)
4.25 (10.8)
3.125 (7.90)
2.00 (5.1)
1.44 (3.7)
3 (1.4)
ALRB008TBC
①
5
7.6
8
2757
4.75 (12.1)
6.50 (16.5)
3.75 (9.50)
2.10 (5.3)
2.00 (5.1)
5 (2.3)
ALRB012TBC
①
7.5
11
12
1838
4.75 (12.1)
6.50 (16.5)
3.75 (9.50)
2.10 (5.3)
2.00 (5.1)
6 (2.7)
ALRB016TBC
①
10
14
16
1378
4.75 (12.1)
6.50 (16.5)
3.75 (9.50)
2.30 (5.8)
2.00 (5.1)
6 (2.7)
ALRB025TBC
①
15
21
25
882
4.75 (12.1)
6.50 (16.5)
4.00 (10.2)
2.60 (6.6)
2.50 (6.4)
9 (4.1)
ALRB027TBC
①
20
27
27
817
4.75 (12.1)
6.50 (16.5)
4.00 (10.2)
2.60 (6.6)
2.50 (6.4)
9 (4.1)
ALRB035TBC
①
25
34
35
630
4.75 (12.1)
6.50 (16.5)
4.50 (11.4)
3.20 (8.1)
2.50 (6.4)
13 (5.9)
ALRB045TBC
①
30
40
45
490
4.75 (12.1)
6.50 (16.5)
4.50 (11.4)
3.20 (8.1)
3.00 (7.6)
14 (6.4)
ALRB055TBC
①
40
52
55
401
7.00 (17.8)
9.00 (22.9)
4.50 (11.4)
3.50 (8.9)
3.60 (9.1)
22 (10.0)
ALRB080TBC 60
77
80
276
7.00 (17.8)
9.00 (22.9)
4.75 (12.1)
3.60 (9.1)
3.60 (9.1)
23 (10.4)
ALRB110CBC 75
96
110
200
7.00 (17.8)
9.00 (22.9)
5.50 (14.0)
3.60 (9.1)
3.60 (9.1)
27 (12.2)
ALRB130CBC 100 124
130
170
7.00 (17.8)
9.00 (22.9)
6.50 (16.5)
3.50 (8.9)
3.60 (9.1)
34 (15.4)
ALRB160CBC 125 156
160
138
7.00 (17.8)
9.00 (22.9)
6.50 (16.5)
4.20 (10.7)
3.60 (9.1)
36 (16.3)
ALRB200CBC 150 180
200
110
7.00 (17.8)
9.00 (22.9)
8.00 (20.3)
4.20 (10.7)
3.60 (9.1)
55 (24.9)
ALRB250CBC 200 240
250
88
8.50 (21.6)
10.80 (27.4)
8.00 (20.3)
5.70 (14.5)
4.60 (11.7)
74 (33.6)
ALRB300CBC 250 302
300
74
8.50 (21.6)
10.80 (27.4)
8.00 (20.3)
5.20 (13.2)
4.60 (11.7)
85 (38.6)
ALRB360CBC 300 361
360
61
8.50 (21.6)
10.80 (27.4)
8.00 (20.3)
6.20 (15.2)
4.60 (11.7)
105 (47.6)
ALRB420CBC 350 414
420
53
8.50 (21.6)
10.80 (27.4)
8.50 (21.6)
6.20 (15.2)
4.60 (11.7)
113 (51.3)
ALRB480CBC 400 477
480
46
8.50 (21.6)
10.80 (27.4)
8.50 (21.6)
6.70 (17.0)
4.60 (11.7)
119 (54.0)
* Motor HP and Amp rated at 480 volts.
①
CE Marked
