Manage:
Medium-duty Battery Switches
772-DBC
NEW
NEW
NEW
NEW
Pro Installer Double
Pole Battery Switch
Same industry standard mounting with
On/Off operation. Used where positive
and negative supplies must be isolated
at the same time.
SAFETY NOTE: BEP does not
recommend this for switching house
and start battery systems at the same
time, for safety reasons. You may need
to isolate your engine battery in an
emergency, but not your house battery
which typically powers the
communications. For this application
please use the new Dual Bank Control
Switch (772-DBC) or one of BEP’s
battery switch clusters.
Note: 770-DP is replacing 720-DP
NEW
NEW
NEW
NEW
Pro Installer Dual Bank
Control Switch
This innovative (Patent Pending) switch
combines the functions of 3 battery
switches into one (House, Start, and
Emergency Parallel) to intuitively
manage 2 battery banks and 2 loads. A
unique safety position isolates one load
e.g. House “On”, Start “Off” in case of
engine malfunction, so an emergency
radio call can still be made. Significant
savings in both space and installation
cost can be made, without
compromising functionality or safety.
NEW
NEW
NEW
NEW
Pro Installer On/Off
Battery Switch
A powerful new generation battery
switch with outstanding performance
and features for both the installer, and
end user. Three mounting options:
surface, rear panel, and front panel
mounting, plus optimized cable access
makes installation a breeze. Pro Installer
switches set the new benchmark with
outstanding ergonomics, intuitive look/
feel, and are engineered from the finest
materials to withstand the harsh marine
environment.
770
770-DP
Specifications
Item #
OEM #
in
LxWxH
mm
LxWxH
Rating (A DC)
Voltage
(V DC) Operation Stud Detail
Cont
Inter Crank
770
770-B 3.85"x3.85"x3.62" 98x98x92 mm 400 600 1500 48
On/Off
2x (3/8" / 10 mm)
— 770-OEM Same specs as above. Bulk packaged switch for panel mounting. No back or sideplates.
770-DP
770-DP-B 3.85"x3.85"x3.62" 98x98x92 mm 400 600 1500 48
On/Off (x2) 4x (3/8" / 10 mm)
771-S
771-S-B 3.85"x3.85"x3.62" 98x98x92 mm 400 600 1500 48
1-2-Both-Off 3x (3/8" / 10 mm)
771-SFD
771-SFD-B 3.85"x3.85"x3.62" 98x98x92 mm 400 600 1500 48
1-2-Both-Off 3x (3/8" / 10 mm)
772-DBC
772-DBC-B 3.85"x3.85"x3.62" 98x98x92 mm 400 600 1500 48
1, 1/2,
Parallel, Off
4x (3/8" / 10 mm)
NEW
NEW
NEW
NEW
Pro Installer Standard Mount Battery Switches
Surface
Mount
Rear Panel
Mount
Front Panel
Mount
Standard Mounting Options
On/Off
Double Pole
1
2
Dual Bank
Control
