toll free 800.307.6702 MASTERVOLT | mastervolt.com MARINCO | marinco.com ANCOR | ancorproducts.com
Manage
|
Battery Switches
Manage:
Medium & Heavy-duty Battery Switches
NEW
NEW
NEW
NEW
Pro Installer Selector (771-S) & Selector with
Field Disconnect (771-SFD) Battery Switches
Power requirements on boats have increased, and these 2 Selector
switches offer high power capacity (400 amps continuous), the ability to
easily fit doubled cables, and conform to the industry standard mounting
footprint (Guest, Perko, Blue Sea).
Please note selector switches will not separate electronics from harmful
engine starting spikes.
Specifications on previous page.
Note: 771-S is replacing 721
771-S
Heavy-duty Battery Switch
The 720 Heavy-duty Battery Switch fits into the same contour lock
system as used on the battery distribution system. Rated at 600A
continuous and 2500A cranking. It is well suited to larger vessels.
As with the 701, the 720 can be recessed or surface mounted. The 720
uses the same style of self cleaning sliding contact as used in the 701
and uses the same label sheet (Item # 713 or 715 see page 149).
720
Specifications
Item #
OEM #
in
LxWxH
mm
LxWxH
Rating (A DC)
Voltage
(V DC) Operation Stud Detail
Cont
Inter Crank
720
720B
4"x4"x3.5"
102x102x90 mm 600 800 2500 48
On/Off
2x (1/2" / 12 mm)
1
2
Selector Switch
(with Alternator
Field Disconnect)
