Manage:
Panel Covers
Item #
Mount
type Cover Description
in
HxWx3.5
mm
HxWx90
BC-FM1
Flange 1 column 8-12 CBs + meter 15"x5"
380x127
BC-FM2
Flange 2 column 8-12 CBs + meter 15"x9.4"
380x239
BC-FM3
Flange 1 column 8-12 CBs
11.2"x5"
285x127
BC-FM4
Flange 2 column 8-12 CBs
11.2"x9.4"
285x239
BC-PM1
Panel
1 column 8-12 CBs + meter 14.2"x4.2"
360x107
BC-PM2
Panel
2 column 8-12 CBs + meter 14.2"x8.6"
360x219
Back Panel Covers
• Designed to insulate exposed rear terminals.
• Flame retardant PVC in two styles.
• Flange Mount: for access to control panel back when mounted in place.
Attaches to the rear of the same mounting surface as the panel.
• Panel Mount: for access only when panel is removed.
Supplied with mounting pedestals.
BC-FM2
BC-PM1
BC-PM2
BC-FM1
