Cruiser Series
• 12V / 24V
• Mimic panel for quick reference of systems in operation
• Blank space for addition of extra meter
• Digital or analog readouts
Double Pole Panels
• Double pole panels available in all panel sizes.
• Double pole CBs use twice the space of single pole
breakers; an 8-way panel can become a 4-way
• AC or DC versions available
• Single toggle
# of
Circuits
in
HxWx2.5
mm
HxWx65
Label
Sheet
CB’s - Single Pole
Digital
Item #
Analog
Item #
5 10 15 20 25 30
32
15x13.9 380x351 1–4, 6 7 11 11 1 1 1
NC32Y-DCSM NC32Y-AM
36
15x13.9 380x351 1–4, 6 8 12 12 2 1 1
NC36L-DCSM NC36L-AM
All analog panels supplied with one shunt, extra shunts ordered separately. Digital panels supplied with 450A – 50mV shunt.
Cutout size – 3/8" (10 mm) inside all external edges
All panels available in 12 or 24V configuration. If 24V is required, please specify when ordering by adding –24V to part number.
NC36L-DCSM
NC32Y-DCSM
Manage:
DC Circuit Breaker Panels
