DC Analog/Digital Meters
• Ammeters available in other scales (page 197).
• All panels are available with either Analog or Digital meters
• Label set and bus bar supplied with panel; for additional
label sets see page 146–147
Manage:
DC Circuit Breaker Panels
# of
Circuits Direction
mm
HxWx65
in
HxWx2.5
Label
Sheet
CB’s - Single Pole
Neg Bus
Digital
Item #
Analog
Item #
5 10 15 20 25 30
4
vertical
200x127 7.9x5
1
1 2 1
6 way
900V-DCSM
900-AM
8
vertical
295x127 11.6x5
1
2 2 3 1
6 way
901V-DCSM 901V-AM
12
square
200x239 7.9x9.75 1
3 4 4
1
6 way
902-DCSM 902-AM
vertical
380x127 15x5
1
3 4 4
1
6 way
902V-DCSM 902V-AM
16
vertical
295x239 11.6x9.75 1–2 4 5 5 1 1
12 way
904-DCSM 904-AM
20
horizontal
200x351 7.9x9.75 1–3 5 6 7 1
1 12 way
903-DCSM 903-AM
24
square
295x351 11.6x13.9 1–3 5 8 8 1 1 1 12 way
905-DCSM 905-AM
vertical
380x239 15x9.75
1–3 5 8 8 1 1 1 12 way
905V-DCSM 905V-AM
32
horizontal
295x463 11.6x18.25 1–4 7 11 11 1 1 1 24 way
906-DCSM 906-AM
vertical
455x239 18x9.75
1–4 7 11 11 1 1 1 12 way
906V-DCSM 906V-AM
48
square
380x463 15x18.25 1–5 12 15 15 3 1 2 2 x 24 way —
907-AM
All analog panels supplied with one shunt, extra shunts ordered separately. Digital panels supplied with 450A-50mV shunt.
Cutout size - 10 mm (3/8") inside all external edges
All panels available in 12 or 24V configuration. All part numbers shown are 12V backlighting.
Order upgrade kits to suit number of breakers in panel. See page 137 for upgrade part number.
For more information on circuit breaker panels go to
marinco.com
900-AM
901V-DCSM
902V-DCSM
902-AM
904-AM
905V-DCSM
906V-AM
