# of
Circuits Direction
in
HxWx2.5
mm
HxWx65
Label
Sheet
CB’s - Single Pole
Neg
Bus
Item #
5 10 15 20 25 30
4
square
4.5"x5"
115x127 1
1 2 1
6 way
900-DC
8
horizontal
4.5"x9.75"
115x239 1
2 2 3 1
6 way
901H
vertical
7.9"x5"
200x127 1
2 2 3 1
6 way
901V
12
horizontal
4.5"x13.9"
115x351 1
3 4 4
1
6 way
902NMH
vertical
11.25"x5"
285x127 1
3 4 4
1
6 way
902NMV
16
square
7.9"x9.75"
200x239 1
4 5 5 1 1
12 way
904NM
horizontal
4.5"x18.25"
115x463 1
4 5 5 1 1
12 way
904NMH
vertical
11.25"x5"
285x127 1
3 4 4
1
6 way
904NMV
24
square
7.9"x13.9"
200x351 1–3 5 8 8 1 1 1 12 way
905NM
vertical
11.25"x9.75" 285x239 1–3 5 8 8 1 1 1 12 way
905NMV
32
horizontal
7.9"x18.25"
200x463 1–4 7 11 11 1 1 1 24 way
906NMH
vertical
14.6"x9.75"
370x239 1–4 7 11 11 1 1 1 24 way
906NMV
36
square
11.25"x13.9" 285x351 1–4, 6 8 12 12 2 1 1 24 way
NC36NM
Cutout size - 3/8" (10 mm) inside all external edges
For more information on circuit breaker panels go to
marinco.com
DC No Meters
• Red systems on LED
• 12V
• Marine grade powder coated aluminium
• ABYC standard voltage indication
• Green LED backlit labels
• Stylish clip on contour fascia
• Label sets and buss bar supplied with panels;
for additional labels see page 146–147
Manage:
DC Circuit Breaker Panels
901V
902NMV
900-DC
902NMH
904NMH
901H
