Single Pole Switchable Manual Reset
Thermal Circuit Breaker
Features:
• Weatherproof IP66 design
• Trip free safety feature
• Switchable circuit protection
• Easy installation/ operation
• Ignition Protected
• CE Approved
Specifications:
•
Rating:
25-200A, 48V DC
•
Interrupt Rating:
Main Breaker Protection Interrupt Rating
(5,000A@ 14V DC, 3,000A@ 28V DC and 1,500A@ 48V DC)
•
Operating Temperature Rating:
-40°F (-40°C) to 185°F (85°C)
•
Storage Temperature Rating:
-40°F (-40°C) to 260°F (125°C)
•
Materials:
Black UL-rated 94V0 thermoset plastic body
• Cover and lever are UL-rated 94V0 thermoplastic
•
Marking:
Standard marking includes amp/volt ratings
•
Termination:
5/16-18 threaded studs
•
Torque Rating:
75 in-lbs (8.5Nm) max
•
Mounting Torque Rating:
Panel or surface-mount options; 50 in-lbs (5.6 Nm) max
•
Ingress Protection Rating:
IP66
•
Compliances:
ABYC E-11; CE; SAE J1171 (ignition protected)
• Available in other sizes upon request, from 25–150 Amps
NEW
NEW
NEW
NEW
Marine Rated Battery Fuse
Features:
• Weatherpoof IP66 design
• Compact heavy duty protection
• Insulated cap to prevent short circuit
• Ignition Protected
• Easy installation
• Suitable for high capacity battery banks
Specifications:
•
Voltage Rating:
58Vdc Maximum
•
Amperage Rating:
30A - 300A
•
Ingress Protection:
IP66
•
Ignition Protected:
Per SAEJ1117
•
Interrupt Rating:
10000A @ 14Vdc, 5000A @ 32Vdc, 2000A @ 58Vdc.
•
Torque Rating:
Maximum 12Nm (106 in-lbs)
•
Material:
Body – Ceramic, Housing & Cover: UL-rated 94V0
• Thermoplastic, Ring Terminals - Tin Plated
•
Compliances:
ISO 8820-6
• Available in other sizes upon request, from 30–300 Amps
Manage:
Circuit Breakers
Mounting Rating (A) Item #
OEM #
Surface
200
MRCBF-200A
MRCBF-200A-B
Panel
200
MRCBP-200A
MRCBP-200A-B
Rating
(A)
Qty/
Pkg Item #
OEM #
50
1
MRBF-50A
MRBF-50A-B
80
1
MRBF-80A
MRBF-80A-B
100
1
MRBF-100A
MRBF-100A-B
125
1
MRBF-125A
MRBF-125A-B
150
1
MRBF-150A
MRBF-150A-B
200
1
MRBF-200A
MRBF-200A-B
MRCBF-200A
MRCBP-200A
MRBF-SET
Terminal mount heavy-duty
fuse holder and cover
