Fuse Holders
ATC Fuse Holders
The BEP™ ATC Fuse Holder provides compact, easy access
to fuses with the design integrity only BEP can offer.
• Allows for multiple fuse holders and bus bars to be joined
together, increasing the number of circuits protected
• Fuse holder inputs can be linked together to form a single
continuous fuse holder
• Includes patented Contour Lock system, see-thru clip-on
cover and label set
• Available with screw terminals or quick connect terminals
• Max. current/circuit: 30A;
Max. current/block: 100A;
Max. voltage: 32V DC;
Base & cover material: polycarbonate
• Positions for spare fuses
• ATC Fuse holder: 80x90x47 mm (3.1"x3.6"x1.9")
• ATC Bus bar: 35x90x47 mm
ATC-6W
Description
Pack Qty Item #
OEM #
6 Way fuse holder
screw terminals w/ cover & link
1/blister
ATC-6W
—
6 Way fuse holder
Quick Connect w/ cover & link
1/blister
ATC-6WQC
—
6 Way bus
w/ 5 mm input stud, cover, joiners
1/blister
80-712-0039-00
—
6 Way fuse holder
screw terminals w/ cover
24/pack —
ATC-6W/B
6 Way bus w/
5 mm input stud, cover, joiners
24/pack —
80-712-0039-01
BB-LINK17MM
allows two 6 way ATC fuse holders to be
joined together providing twelve fused
positions running off one feed
ATO/ATC Fuse Panels
• Common negative bus with “push-on” tabs
• Common positive feed
• Each branch handles up to 30 amps
(160A max total)
• 3.75"w x 3.375"h x .8125"d
Item # 607122
6 Gang
ATC Bus Bar
The expandable ATC negative
Bus uses the BEP™ Contour
Lock system to allow it to be
joined to the ATC fuse holder.
This keeps wiring tidy and
conveniently located.
Current rating 100A.
80-712-0039-00
