BI 702-S
BI 703
BI 1202-S
BI 1203-S
Item #
83007021
83007030
83012021
83012031
Max. output charger 25/50A
25/50A
80A
80A
Max. output alternator 70A
70A
120A
120A
Compensation diode yes
no
yes
yes
Dimensions, hxwxd
6.2"x5.5"x3.2"
157x140x80 mm
8.2"x5.5"x3.2"
207x140x80 mm
8.2"x5.5"x3.2"
207x140x80 mm
8.2"x5.5"x3.2"
207x140x80 mm
Weight
1.3 lbs / 0.58 kg 2.4 lbs / 1.1 kg 2.65 lbs / 1.2 kg 2.9 lbs / 1.3 kg
# of battery banks
2
3
2
3
BI Battery Isolators
Mastervolt’s BI battery isolators
are based on conventional
diode technology. The diode
voltage drop (ca. 0.6 V) can
be compensated for by
adapting the output voltage
of the connected charger
or alternator. Mastervolt
battery chargers and Alpha
Pro MB charge regulators
come as standard with
automatic compensation
for voltage drops.
Manage:
Battery Isolators
Battery Mate
While battery isolators are conventional diode
splitters, the Battery Mate’s technology is
electronic and includes mosfets (transistors).
Its components compensate for the voltage
drop and ensure that charging continues at the
right voltage level, even with several battery
banks. The Battery Mate is compatible with any
type of alternator/battery charger, in both
existing and new systems. As the voltage loss
between the alternator and battery is negligible,
the Battery Mate performs far better than
conventional battery isolators. This ensures fast
and complete charging of your batteries
without having to make additional adjustments
to the alternator.
Battery Mate
1602 IG
Battery Mate
1603 IG
Battery Mate
2503 IG
Item #
83116025
83116035
83125035
Max. output charger
120A
120A
200A
Max. output alternator 160A
160A
250A
Dimensions, hxwxd 8.2"x5.5"x3.2"
207x140x80 mm
8.2"x5.5"x3.2"
207x140x80 mm
8.2"x5.5"x3.2"
207x140x80 mm
Weight
2.2 lbs / 1 kg
2.2 lbs / 1 kg 2.2 lbs / 1 kg
# of battery banks
2
3
3
Battery Watch
The Battery Watch is an essential element of any well-equipped battery
system, offering you a 1.3 lbs electronic watchdog that ensures a much
longer lifespan for your batteries. The unit switches off loads when
batteries are nearly empty, to keep your batteries in optimum condition.
LED lights provide a clear read out and the undervoltage can be set
using DIP switches.
Item #
83200150
Max. load
150A
Input voltage
8-32V DC
Switch off under voltage 12V 9-12V DC
Switch off under voltage 24V 18-24V DC
Dimensions (LxWxH)
6.2"x5.5"x3.2"
157x140x80 mm
Weight
1.3 lbs / 0.6 kg
Fail-Safe Galvanic Isolators
• Gold plated terminals provide superior corrosion
resistance for harsh environment exposure
• Prevent galvanic corrosion due to dissimilar metals
between boats
• Block DC current from flowing
through shore power cable
• Ignition Protected
• ABYC - A28 compliant to "fail-safe" requirements
Item #
4531001
4531011
Voltage Rating
115/230V AC 115/230V AC
Frequency Rating 50/60Hz
50/60Hz
Current Rating
30A at 50°C 50/60A at 50°C
Operating Temp
-20 to 50°C -20 to 50°C
Dimensions (HxWxD) 5.6"x5.8"2.5"
14.1x14.7x6.5cm
10.3"x5.8"x2.5"
26.2x14.7x6.5cm
