Circuit Protection & Panels
Manage:
Fuses
Maxi-Blade Fuses
Fuses available: 30-80A
Interrupt capacity: 1000A DC
Maximum voltage: 32V DC
Rating
(A)
Qty/
Pkg Item #
OEM #
30
1
BFHD-30A/DSP
BFHD-30A
40
1
BFHD-40A/DSP
BFHD-40A
50
1
BFHD-50A/DSP
BFHD-50A
60
1
BFHD-60A/DSP
BFHD-60A
70
1
BFHD-70A/DSP
BFHD-70A
80
1
BFHD-80A/DSP
BFHD-80A
NEW
NEW
NEW
NEW
Medium-duty Class T Fuses
Interrupt Capacity: 20,000A DC
Maximum voltage: 160V DC
Diameter: 1.34" (34 mm)
Length: 2.77" (70mm)
Use with:
• New Pro Installer Class T Fuse Holders (page 161)
Rating
(A)
Qty/
Pkg
OEM #
225 1 FT-225-B
250 1 FT-250-B
300 1 FT-300-B
350 1 FT-350-B
400 1 FT-400-B
NEW
NEW
NEW
NEW
Heavy-duty Class T Fuses:
Interrupt Capacity: 20,000A DC
Maximum voltage: 160V DC
Diameter: 1.62" (41 mm)
Length: 3.03" (77mm)
Use with:
• New Pro Installer Class T Fuse Holders (page 161)
Rating
(A)
Qty/
Pkg
OEM #
450 1 FT-450-B
500 1 FT-500-B
600 1 FT-600-B
NEW
NEW
NEW
NEW
Heavy-duty ANL Fuses
Use with:
• 5/16" (8 mm) mounting studs
• New Pro Installer ANL Fuse Holders (page 161)
Rating
(A)
Qty/
Pkg
OEM #
600
5 FANL-600-B
675
5 FANL-675-B
750
5 FANL-750-B
ANL Fuses
Use with:
• New Pro Installer ANL Fuse Holders (page 161)
• DC Distribution 500 (Item # 77020200) on page 181
• ANL Fuse Block below (Item # 607006)
Length: 3.23" (82 mm)
Width: 0.88" (22 mm)
Stud Clearance: 0.43" (11 mm)
Rating
(A)
Qty/
Pkg Item #
OEM #
20
1 —
77049020
40
1 —
77049040
50
1
IP50P/DSP
77049050
63
1
IP63P/DSP
77049063
80
1
IP80P/DSP
77049080
100 1
IP100P/DSP
77049100
125 1 —
77049125
150 1
IP50P/DSP
—
160 1 —
77049160
175 1 —
77049175
200 1
IP200P/DSP
77049200
250 1
IP250P/DSP
77049250
300
1
IP300P/DSP
77049300
355
1
IP355P/DSP
77049355
400
1 —
77049400
425
1
IP425P/DSP
77049425
500
1
IP500P/DSP
77049500
See page 132 for Marine Rated Battery Fuses
