toll free 800.307.6702 MASTERVOLT | mastervolt.com MARINCO | marinco.com ANCOR | ancorproducts.com
Single pole
Rating
(A)
Double pole
Rating
(A)
Triple pole
Rating
(A)
CBS-5A-SP
5
CBS-10A-DP
10
CBS-50A-TP / 50
50
CBS-10A-SP
10
CBS-15A-DP
15
CBS-15A-SP
15
CBS-20A-DP
20
D / Pole trip coil
Volts (V)
CBS-20A-SP
20
CBS-25A-DP
25
CBS-15A-DP-TC230
230
CBS-25A-SP
25
CBS-30A-DP
30
CBS-20A-DP-TC230
230
CBS-30A-SP
30
CBS-40A-DP
40
CBS-30A-DP-TC230
230
CBS-40A-SP
40
CBS-50A-DP
50
CBS-50A-DP-TC230
230
CBS-50A-SP-IG
50
Compatible with BEP panels
Single pole
Rating
(A)
Double pole
Rating
(A)
Triple pole
Rating
(A)
CBL-50A-SP
50
CBL-50A-DP
50
CBL-80A-TP
80
CBL-60A-SP
60
CBL-60A-DP
60
CBL-100A-TP
100
CBL-75A-SP
75
CBL-75A-DP
75
CBL-100A-SP
100
CBL-100A-DP
100
Compatible with BEP panels
IEG Magnetic CBs
IEG magnetic circuit breakers provide reliable circuit protection and
accurate circuit control for equipment in the international market place.
Designed using the latest in sensitive hydraulic magnetic technology, the
IEG line adapts itself to many applications and environments. They are
ideal for marine applications, data processing and business machines,
as well as medical instrumentation, broadcast equipment, vending and
amusement machines, military applications and wherever precision
operation is required. Temperature differences which affect fuses and
other thermal devices are not a concern. One important feature of this
breaker line is a ‘trip free’ action, which means the circuit will trip in the
presence of an overload even though the handle is held in the ON
position. The delay mechanism senses the fault and the contacts open.
• Spacing compliance: IEC specification 601, 950; VDE 0804, 0805
• UL recognized; CSA certified; VDE 0660 approved; Part 101 &
CE compliant
• Available in single or double pole; triple pole available on special orders
IUL Magnetic CBs
Provide reliable circuit protection and accurate circuit control for equipment
in the international market place. BEP uses the IUL range of circuit breakers
where current requirements exceed 50A and are within 100A. Available in
single and double pole with triple pole available on special orders.
CBS-50A-SP-IG
CBL-50A-SP
CBS-50A-DP
CBL-100A-DP
Manage:
Circuit Breakers
[3.56]
.140
[3.61]
.142
[47.22]
1.859
ON
OFF
[7.14]
.281
[49.28]
1.940
[36.78]
1.448
[10.97]
.432
[52.32]
2.060
M6 ISOTHD
2x
Ă
.156
[3.96]
MAX.
[38.48]
1.515
[19.05]
.755
[5.59]
.220
[36.53]
1.438
[63.24]
2.490
[10.21]
.402
[52.32]
2.060
M3 ISOTHD
.750
[19.05]
Single Pole Double Pole
Note:
Tolerance
.015 [.38]
unless noted.
Dimensions in
brackets [] are
millimeters.
Panel Mounting Detail:
Tolerance .013 unless noted.
