Manage:
Battery Distribution Panels
5 Way CB Panel
• 1x Heavy-Duty CB, 1x Toggle, 3x Push Reset
• Equipped to cover essential circuits requirements
(bilge, pumps etc)
• 50A CB for DC mains or treatment systems
• 135A 185 Series CB for anchor windlass
• Compliments the other modules for either single or dual
engine installations
Item # CC-804
The below panels are designed for applications where the
OEM or panel builder wishes to construct a custom
system. They’re supplied as empty panels with all
necessary mounting hardware, including one CC-joiner.
CC-2 Module
Will house the following components:
CLB series (push reset) Carling circuit breakers (page 133).
Toggle Magnetic Hydraulic Carling circuit breakers
(page 130).
BEP CB Panel Mount
The CC-HDBM module must be ordered separately if
ordering BEP™ 184 & 185 series circuit breakers.
Mounting hardware for CB and panel attachment is
supplied with module.
CC-HDBM
CC-1 & CC-5 Modules
Will house the following components:
701-PM Panel mount battery on/off (page 103).
701S-PM Panel mount battery selector switch (page 103).
185 Series Heavy-duty circuit breakers (page 131).
(CC-HDBM must be ordered with 185 series circuit breakers,
one per breaker).
710-140A Voltage Sensitive Relay (see page 111).
CC-1
CC-5
Blanking Plate
The CC-BLANK will cover an unused
hole in CC-1 and CC-2. Attached
from the rear of the panel, it allows
for expanding with other options at a
later date.
Item # CC-BLANK
Wave Strips
• Supplied with Contour Connect panels (standard)
• Can be ordered seperately (top and bottom pair)
• Available in single, double and triple lengths
Item # CC-3WS/CH
Item # Application
708-42.5
For horizontal linking of battery switches
in the same panel
708-70.0
For horizontal linking of battery switches
studs between 2 separate panels
708-107
For vertical linking of battery switches
between panels
Solid Links
708-42.5 Solid terminal links supplied
pre-connected with spare links for different
orientations (horizontal or vertical) of
Contour Connect panels.
Must be ordered separately when
ordering CC Kitset panels.
708-42.5
