Single Engine, Two Battery Banks
This panel incorporates a version of our very
successful 714-140A-DVSR cluster (page 113).
Supplied pre-wired with back cover and CC-J joiner
to allow it to be combined with other modules.
Supplied standard in charcoal with grey wave strip.
Other trim colors are available for volume
OEM orders.
Item # CC-801
Twin Engine, Three Battery Banks
The CC-803N incorporates a version of our very successful dual engine battery
switch cluster (page 115).
The CC-803N is supplied with cables to allow for horizontal or vertical configurations.
The components can also be easily removed and reconfigured if the factory
layout does not suit your application.
Item # CC-803N
Manage:
Battery Distribution Panels
Single Engine, Two Battery Banks
The CC-810 is supplied standard with 3 x
701-PM battery switches pre-assembled.
Ideal for installing alongside any other Contour
Connect Modules.
Item # CC-810
Single Engine, Two Battery Banks
The CC-802 incorporates a version of our very
successful single engine battery switch cluster
(page 114).
The CC-802 is supplied loosely assembled with
links and joiners to allow it to be assembled in
either the vertical or horizontal orientation as
shown in illustrations.
Full wiring instructions are supplied to allow
pre assembly for both orientations.
Item # CC-802
Dimensions for Contour Connect Panels
Item #
LxWxH in
LxWxH mm
Module
Cut-out
Module
Cut-out
CC-801
6.5"x4.2"x2.2"
5.75"x3.4" 166x106x55 mm 146x86 mm
CC-810
9.2"x4.2"x2.2"
8.5"x3.4"
233x106x55 mm 213x86 mm
CC-802
6.5"x8.3"x2.2"
5.75x7.5"* 166x212x55 mm 88x148 mm*
CC-803N
9.2"x8.3"x2.2"
8.5"x3.4"* 223x212x55 mm 213x86 mm*
*Single hole only.
Battery
Distribution Panels
Fast fit, flush mounting battery
distribution panels
1. Use template to mark
rectangular hole in fascia
2. Cut hole
3. Fit panel and screw into place
4. Add trim pieces
5. Connect cables
