Manage:

Custom Panel Template

METER POSITION 1

CONTROL

METER POSITION 2

CONTROL

METER POSITION 3

CONTROL

METER POSITION 4

CONTROL

NAV LTS

ANCHOR LTS

CABIN LTS

SPOT LTS

10A

15A

See label index starting on page 146

Custom Panel Layouts

Although the panels shown in this catalog are our standard

range, there are a number of changes that can be made to fit

the needs of custom and production boatbuilders. For example,

a panel can be made up with eight circuit breakers, four

systems in operation lights plus a meter, or a panel can consist

of a mixture of analog and digital meters if required.

If the panel involves a total

custom layout, as described

above, a specific Item # will

be applied to that panel and

quoted accordingly.

If the design is unable to

be achieved we will notify

the customer.

Alternatively a customer

may request a standard

panel with circuit breakers

laid out to their requirements

with labels factory fitted.

This involves a personalized

layout charge with the

following part numbers

applying, eg:

901V is ordered as

NPF-901V.

902A-12V-12V is ordered

as NPF-902A-12V-12V

When ordering personalized

panels see our label

selection that starts on

page 146. We can also do

specific label sets, priced

per-job.

Circle your selections:

Voltage:

12V

24V 110V 230V

Backlighting:

12V

24V

Meters:

Yes

Blank

Digital:

ACSM

(page 192)

DCSM

(page 191)

600-VM3 600-TG 600-SOM

Meter Position:

Anlg Volts DC:

8-16 16-32

Meter Position:

1 2 3 4

Anlg Amps DC:

0- 50 0-100 0-150

Meter Position:

1 2 3 4

Anlg Volts AC:

0-150 0- 300

Meter Position:

1 2 3 4

Anlg Amps AC:

0-60 0-100AAC

Meter Position:

1 2 3 4
