toll free 800.307.6702 MASTERVOLT | mastervolt.com MARINCO | marinco.com ANCOR | ancorproducts.com
Item #
charcoal
Item #
white
Fuses PTC LxWxH
Label
Sheet
CSP6
CSP6W
No No 6.25"x4.4"x2.5"
158x112x64 mm
SET-1SP
CSP6-F CSP6-FW
3
No
CSP6-PTC CSP6-PTCW
No 6
Contour Switch Panel
• CSP6-PTC(W) uses the latest in overload protection technology -
Positive Temperature Co-efficient
• Green LED backlit labels; red systems on indicator
• Switches rated 20A DC
• Removable cover plates conceal screws & water drain
• Label set SET-1SP included, additional label sets available, see page 148
•
CSP6(W)
Includes 6 switches unfused for installation where separate fused
supply is available.
•
CSP6-F(W)
Includes 6 switches and 3 inline fuse holders with fuses behind panel.
•
CSP6-PTC(W)
fuses are solid state resettable fuses which change to a high
resistance device on over-current. The panel is supplied with 6 x 9A PTC fuses
mounted internally. No more changing fuses!
CSP6
Manage:
Sprayproof Switch Panels
Manage
|
Circuit Protection & Panels
Item #
Description Operation
SW-32111
Switch
on/off
SW-32113
Switch
on/on
SW-32114
Switch
on/off/on
SW-32115
Switch
(on)off/momentary
SW-32120
Switch
(on)off(on) momentary
SW-32123
Switch
on/off/on double pole
SW-M331
Boot
Splash proof cover
12VPG
Deluxe 12 volt plug
12VRC
Deluxe 12 volt receptacle
WAFH-14
Inline ATC fuseholder
WAFH-14
SW-M331
12VRC
12VPG
Spare Parts
Compatible with Waterproof and Micro Series panels
(opposite page) and Contour Switch Panel above.
See page 38 for product details and OEM versions
