Manage:
Toggle Switches
Contour 1100 Series
The Contour Interior switch can be either surface or recess mounted.
The interior series is supplied standard with a three terminal on/on
switch which can be used for on/off circuits or two way light
installations. For applications, eg: shower drain pumps or electric
toilets, momentary switches can be interchanged into the switch plate.
Switches can be turned 90º for horizontal mounting, and all
are current rated at 10A DC.
All switches include a label sheet
For reference, see page 148
Replacement and/or different
Operational Switch
Description
Item #
On/On (On/Off)
SW-6064B3P
On/Off/On
SW-6064C3P
On/Off Spring-loaded
in “on” position
SW-6064D3P
Item #
1100-BK
1101-BK
1101-BK-TS
Interior/Exterior
Interior
Interior
Exterior
Single/Double
Single
Double
Double
Rated
10A
10A
20A
LxWxH
2.4"x1.2"x0.75"
60x30x18 mm
3.6"x1.2"x0.75"
91x30x18 mm
3.6"x1.2"x0.75"
91x30x18 mm
Description
Color Item #
OEM #
12V
Latching On/Off
Red
80-511-0001-00
80-511-0001-01
Latching On/Off
Blue
80-511-0003-00
80-511-0003-01
Momentary (On)/Off Red
80-511-0002-00
80-511-0002-01
Momentary (On)/Off Blue
80-511-0004-00
80-511-0004-01
Buzzer
Red
80-511-0009-00
80-511-0009-01
Description
Color Item #
OEM #
24V
Latching On/Off
Red
80-511-0005-00
80-511-0005-01
Latching On/Off
Blue
80-511-0007-00
80-511-0007-01
Momentary (On)/Off Red
80-511-0006-00
80-511-0006-01
Momentary (On)/Off Blue
80-511-0008-00
80-511-0008-01
Buzzer
Red
80-511-0010-00
80-511-0010-01
NEW
NEW
NEW
NEW
12 & 24V Push-button Switches & Buzzers with LED Ring
New push-button Switches & Buzzers are built to last with their stainless steel
components and silver alloy contacts. The through panel mount switches are
ideal for lighting, switch, or dash panels, with colored rings that can be wired
to either display power to the system or switch back lighting. The product
line includes both switches and warning buzzers with LED light rings.
Features & Benefits:
• Maximum switch current rating 5 Amps
• IP67 environmental protection switches
• IP50 environmental protection buzzers
• 80 decibel buzzer sound intensity
• Warning buzzers flash red on alarm
LED +
NORMALLY OPEN
NORMALLY CLOSED
COMMON
LED -
TOP
O I
C
-
+
NO NC
TOP
22 [0.9"]
10 (0.4") Max
2 [0.1"]
37 [1.4"]
19 [0.7"]
25
[1.0"]
25
[1.0"]
10
[0.4"]
12
[0.5"]
12
[0.5"]
22
[0.9"]
22
[0.9"]
22 [0.9"]
10 (0.4") Max
2 [0.1"]
54 [2.1"]
19
[0.7"]
PUSH-BUTTON SWITCHES
BUZZER UNITS
