Item #
in
LxWx1.6
mm
LxWx40
Label
Sheet LEDs
Alarm
Mute
switch
SOP1
4.5"x5"
115x127 1
4
No No
SOP1-AL
4.5"x5"
115x127 1
3+1 switch Yes Yes
SOP2
4.5"x9"
115x239 1–2 8
No No
SOP2-AL
4.5"x9"
115x239 1–2 7+1 switch Yes Yes
59.71mm (2 3/8
”)
32.20mm (1 1/4
”)
48.30mm (1 7/8
”)
Ø51mm (
Ø2
”
)
Ø3.00mm (
Ø1/8
”
)
48.30mm (1 7/8
”)
71.00mm (2 13/16
”)
66.80mm (2 5/8
”)
13.80mm (9/16
”)
29.10mm (1 1/8
”)
Meters Item # Range
Division
Marks Shunt Type
Amp
(DC)
N010A
0-10A DC 0.5A Internal
N020A
0-20A DC 1A
Internal
N050A
0-50A DC 2A
50A-50mV
N0100A
0-100A DC 5A
100A-50mV
N0150A
0-150A 1A
150A-50mV
When ordering optional external shunt ammeters, shunts must
be ordered separately.
Analog
• Analog meters as used in BEP™ Contour circuit breaker panels.
• All analog meters accurate to within 2.5%
Systems in Operation Panels
• 10 mm red LED’s giving important systems
on information
• Ideal for flybridge or remote dash position.
Also available with alarm and mute switch.
• Backlit labels
SOP1
SOP2
NO60ACT
Meters Item #
Range
Division
Marks
Volt
(DC)
N816DCV
8-16V DC 0.2V
N1632DCV
16-32V DC 0.4V
Volt
(AC)
N0150ACV
0-150V AC 10V
N0300ACV
0-300V AC 20V
Amp
(AC)
N060ACT
0-60A AC 5A
N0100ACT
0-100A AC 5A
CT-10-AN must be ordered when using N060ACT
or N0100ACT.
N816DCV
NO300ACV
NO100A
Manage:
Monitoring–Analog
