Manage
|
Monitoring
Tank Sender
• Well nut hole size 3/8" (9 mm).
• Cable length 5 m.
• One kit supplied with 600-TG.
Item # 600-TGSK
Tank Sender
Suits tanks with maximum depth of 280 mm and a maximum
wall thickness of 10 mm, and a maximum hole size of 22 mm.
Comes with 5 m cable.
Item # RV-TS-5M
Tank Sender Interface Module
• Only required when using VDO (10-180) or Centroid (10-180)
or Teleflex (240-33) senders to produce a 0–5V signal to
operate the 600-TLM-N.
• Switchable link for VDO or Teleflex signal. 10-32V supply.
• One unit per sender required.
• Dimensions: 2.4"x1.3"x.9" (60x34x22 mm)
Item # 600-TLM-SIF
LED Tank Gauge
The 600-TG offers economical monitoring for fresh or grey water
tanks (plastic or fiberglass only). Using 600-TGSK strategically
mounted well nuts will give 4 tank levels. Supplied with one
sender kit. Second sender ordered separately.
Also available is the RV-TS-5M Tank sender. Only one hole is
required for installation, the sender is sealed via external lock
nuts. Suitable for tanks with maximum depth of 280 mm.
Item # 600-TG
Manage:
Monitoring–Battery & Tank
Item #
70403163
Number of battery sets
service (fully), starter & bowthruster
Max. amp-hour capacity
9999Ah
Voltage read-out
yes
Current read-out
yes
Amp-hours read-out
yes
Time remaining indication
yes
Battery capacity in %
yes
Current consumption (backlight off) 14 mA/12V - 11 mA/24V
Current consumption (backlight on) 100 mA/12V - 50 mA/24V
Supply voltage
9-35V DC
Voltage range measurement
7-35V DC
Voltage resolution
0.01V
Voltage deviation
± 0.6% ± 1 figure
Amps measurement range
0-500A (optional 1000A/50mV)
Shunt specification
500A / 50mV (included)
Dimensions instrument (WxH)
4.7"x2.6" / 120x65 mm
Built-in depth incl./excl. cover box
2.2"/1.6" / 55/40 mm
Weight instrument incl. shunt
2 lbs / 0.9 kg
Dimensions shunt (HxWxD)
3.3"x1.7"x1.7" / 84x44x44 mm - M8
Masterlink BTM-III Battery Monitor
Provides an accurate indication of the current,
amperage, remaining time and remaining
capacity of battery bank 1, and the current and
estimated capacity of battery banks 2 and 3.
The built-in microprocessor calculates the
remaining capacity and stores historic data.
Tank Level Senders
