Surge Protection Module
Protect your electronics from becoming
damaged by harmful high voltage
spikes. When fitted to the battery supply
these modules look for sudden increases
in voltage then switch into protection
mode to absorb and suppress the high
energy spike.
Item # 80-707-0004-00
12V DC
Item # 80-707-0005-00
24V DC
Heavy-duty Current
Transformer
Maximum current 150A AC
CT-HD is available for systems
with large mains cables, too large
for CT-10-3 (ordered separately).
CT-HD dimensions: Ø 1.85 x 0.4"
(Ø 47 x 10.5 mm)
Hole size: 1.25" (32 mm)
Item # CT-HD
Current Transformer
Maximum current 150A AC
One CT-10-3 current transformer is
supplied with ACSM. If a twin line system is
in use, a second CT must be ordered.
Dimensions:
1.5"x1.55"x.55" (37.5x39.2x13.7 mm)
Hole size: 0.5" (12 mm)
Supplied with 80-600-0023-00
Item # CT-10-3
CZone™-MasterBus Bridge Interface
The CZone™-MasterBus bridge has been developed to connect two
great systems together to bring you the best of both worlds The bridge
physically connects the MasterBus and CZone™ networks together
enabling the two networks to communicate and act as one, providing
seamless control and monitoring of devices on both networks from
either MasterBus or CZone™ displays
Features/Functions
• Control Mastervolt inverters and chargers from CZone™ displays
and switches
• Control of MasterBus output devices (turn lights, pumps, etc. on/off)
• Control of CZone™ output devices (turn lights, pumps, etc. on/off)
via MasterBus displays and switches
• Display CZone™ acquired systems information such as tank
and power levels on MasterBus displays
• Display MasterBus acquired systems information such as tank
and power levels on CZone™ displays
• Transfers alarms between both systems
• 2.75"x2.75"x2" (69x69x50)
Item # 80-911-0072-00
CZone™ Network Bridge Interface
For isolating sections of an NMEA 2000 network
to decrease standby current draw. Isolation
when bridging between two CAN networks, (eg
connecting CZone™ to Simrad Simnet). For
expansion of the NMEA 2000 network when the
maximum node limit for the network has been
reached (node = any device connected to the
NMEA 2000 network). Once fitted, a further 40
nodes can be added.
Item # 80-911-0057-00
Manage
|
CZone
™
Manage:
CZone
™
Digital Control Accessories
