Single Tee Connector
Connects a single device into the
NMEA backbone.
Item # 80-911-0029-00
2 Way Tee Connector
Connects multiple devices into the
NMEA backbone.
Item # 80-911-0047-00
4 Way Tee Connector
Connects multiple devices into the
NMEA backbone.
Item # 80-911-0048-00
TM
CZone™ Digital Control Accessories
Item # 80-911-0050-00
Item #
80-911-0051-00
Male Banking Cap
Protects unused Tee Connector from
dust and water.
Female Banking Cap
Protects unused Tee Connector from
dust and water.
Terminating Resistors
Use at either end of the NMEA backbone
to complete the network. Each network
must have a make and female terminator.
Item # 80-911-0030-00
Female
Item # 80-911-0031-00
Male
Item # 80-911-0024-00
16 ft 5 m
Item # 80-911-0025-00
32 ft
10 m
Item # 80-911-0026-00
1.6 ft .5 m
Item # 80-911-0027-00
6.5 ft 2 m
Extension Cable
Carries power and data along backbone
to NMEA 2000 devices.
Power Cable for
Display Interface
Supplies power for the 3.5" display
interface.
• 2 pin, 6.5 ft (2 m)
Item # 80-911-0032-00
Power Cable
Provides power to the NMEA 2000
network and devices
• 3.2 ft, 1 meter
Item # 80-911-0028-00
90° Elbow Connector
Connects cable together in tight spaces.
NMEA 2000 Network.
Item #
80-911-0046-00
AC Transducer
• The AC-VSEN-4 includes
3 voltage transformers for up to 3
voltage inputs.
• Dimensions: 2.75"x5.5"x2"
(69x140x50 mm)
Item # AC-VSEN-4
CZone Wireless Remote Kit
Simple to set up, wireless remote control.
Buttons are configurable for momentary
on or latching control of circuits.
• 80m (250 ft) operating range
• Rolling code
Item # 80-911-0045-00
Manage:
CZone
™
Digital Control Accessories
