Propel
|
Electric Propulsion
Propel:
Choose your Propulsion Kit & Throttle Control
Choose your system
The overview below provides several system recommendations based on weight and
application. Heavier vessels from around 55 ft for motor and sail yachts and from around
60 ft for catamarans always require a bespoke solution. These recommendations are
intended as guidelines only. Always consult your Mastervolt specialist for the best
configuration.
Required Capacity (guideline)
Motor yacht
Sail yacht
Catamaran
Weight
Length Power Length Power Length Power
1 T / 1000 kg
≤
16' / 5 m 2.5 kW
≤
20' / 6 m 2.0 kW
≤
20' / 6 m 2x 1.0 kW
2 T / 2000 kg
≤
23' / 7 m 5.0 kW
≤
30' / 9 m 4.0 kW
≤
30' / 9 m 2x 2.0 kW
3 T / 3000 kg
≤
30' / 9 m 7.5 kW
≤
36' / 11 m 6.0 kW
≤
36' / 11 m 2x 3.0 kW
4 T / 4000 kg
≤
36' / 11 m 10.0 kW
≤
39' / 12 m 8.0 kW
≤
39' / 12 m 2x 4.0 kW
5 T / 5000 kg
≤
39' / 12 m 12.5 kW
≤
43' / 13 m 10.0 kW
≤
43' / 13 m 2x 5.0 kW
6 T / 6000 kg
≤
43' / 13 m 15.0 kW
≤
46' / 14 m 12.0 kW
≤
46' / 14 m 2x 6.0 kW
7 T / 8000 kg
≤
46' / 14 m 20.0 kW
≤
49' / 15 m 15.0 kW
≤
49' / 15 m 2x 7.5 kW
Choose your propulsion kit and throttle control
Total package
Mastervolt delivers all its electric motors with a controller, cables, display, contact key,
main switch and main fuse. Due to the wide variety in designs, materials and shapes,
throttle handles are not included as standard.
Throttle controls
The Mastervolt ControlMaster throttle controls were specifically designed for electric
sailing and ensure that the speed of your vessel can be subtly and carefully controlled.
Another important issue is an easily identifiable neutral gear. Your choice of throttle
control will depend on your preference in design, shape and materials. All our throttle
controls were developed using corrosion-proof materials and are easily installed. The
kits can be equipped with all available throttle controls.
Practical tips:
• Permanent Magnet (PM)
motors are very compact and
silent; Asynchronous motors
are exceptionally quiet and
have a very high torque.
• To find your most suitable
batteries, go to
mastervolt.
com/batteries
• A proper battery charger is
essential for the maintenance
and lifespan of your batteries.
See
mastervolt.com/chargers
for assistance with your
selection.
• A reliable battery monitor is a
must. See
mastervolt.com/
batterymonitor
• The number of sailing hours
depends on your battery kit
combined with the generated
capacity. For six to eight hours
sailing, you require 4.6 x kW
motor capacity in kWh.
Example: 4.6 x 3.5 kW =
16.1 kWh; this is the capacity
required for six to eight
hours sailing.
ControlMaster Casual
ControlMaster Sport
ControlMaster Sport TD
141500010
141500030
141400220
single version
single version
double version
for all propulsions
for all propulsions
for all propulsions
side assembly
side assembly
top assembly
