Propel
|
Electric Propulsion
Propel:
PodMaster Series & HybridMaster
Voltage
regulator Max. RPM
Required battery capacity for
Type
Capacity
Motor
technology
3–4 hrs
sailing
6–8 hrs
sailing
Item #
PodMaster 2*
2 kW PM
24V
1800 5.6 kWh 9.2 kWh
140600200
PodMaster 4.2
4.2 kW synchronous 48V
1500
11.8 kWh 19.3 kWh
140600420
PodMaster 10
10 kW synchronous 48V
1800
28 kWh
46 kWh
140601000
PodMaster 2 Steerable**
2 kW PM
24V
1800 5.6 kWh 9.2 kWh
140700200
PodMaster 4.2 Steerable** 4.2 kW synchronous 48V
1500
11.8 kWh 19.3 kWh
140700420
PodMaster 10 Steerable**
10 kW synchronous 48V
1800
28 kWh
46 kWh
140701000
PodMaster 6.5 Professional*** 6.5 kW synchronous 48V
950
18.2 kWh 30 kWh
141300650
PodMaster 10 Professional*** 10 kW synchronous 48V
1050
28 kWh
46 kWh
141301000
* Delivered with fixed propeller, also available with folding propeller.
** This PodMaster model is also as Sterndrive available.
*** Supplied without propeller.
Hybrid sailing: Best of both worlds
The HybridMaster is Mastervolt’s solution for hybrid propulsion:
combining the advantages of electric propulsion with the sailing radius
of a diesel engine. The HybridMaster series has an electric power rating
ranging from 3.5 to 10 kW, allowing them to be combined with diesel
engines of up to 150 hp. When sailing electrically, the HybridMaster
gets its energy from the batteries. When sailing on the motor, the
batteries are recharged up to a maximum of 150 A. With the Mastervolt
HybridMaster you can enjoy the best of both worlds.
Type
Capacity
Motor
technology
Voltage
regulator
Item #
HybridMaster 4.8
4.8 kW PM
48V
140103000
HybridMaster 3.5 Ultra 3.5 kW asynchronous
48V
140320350
HybridMaster 7.5 Ultra 7.5 kW asynchronous
48V
140320750
HybridMaster 10 Ultra 10 kW asynchronous
48V
140321000
HybridMaster
Universally applicable and can be installed parallel to the propeller shaft.
The gear ratio between the rpm of the electric motor and the propeller
shaft can be adapted, which is crucial as it ensures that the electric
propulsion is optimally adjusted to the existing propeller and motor.
HybridMaster Ultra
The top end of the line, using completely silent and maintenance-free
brushless asynchronous motor technology.
