Propel:
DriveMaster & PodMaster Series
DriveMaster series
The DriveMaster propeller systems are ideal when size and
space are limited, and remain very much a solution for today.
The special and compact permanent magnet motor offers a high
constant torque with a low rpm, directly transferred to the
propeller without transmission.
DriveMaster Ultra series
DriveMaster Ultra asynchronous systems are specially designed
for applications where capacity and reliability are crucial in all
conditions. The modern brushless asynchronous electro-motors
are watertight (IP65), air-cooled, entirely maintenance-free and
incredibly quiet. The asynchronous technology enables a
considerably higher temporary capacity. Thanks to the fully
automated Powerboost function (+20%), fast maneuvering and
short bursts of speed are even easier to attain.
Voltage
regulator
Max.
RPM
Required battery capacity for
Type
Capacity*
Motor
technology
3–4 hrs
sailing
6–8 hrs
sailing
Item #
DriveMaster 2.5
2.5 kW PM
24 V
1100 7 kWh
11.5 kWh
140100250
DriveMaster 3.6
3.6 kW PM
48 V
1600 10 kWh
16.5 kWh
140100360
DriveMaster Ultra 3.5**
3.5 kW asynchronous 48 V
1450 9.8 kWh 16 kWh
140300350
DriveMaster Ultra 7.5**
7.5 kW asynchronous 48 V
1450 21 kWh
34.5 kWh
140300750
DriveMaster Ultra 10**
10 kW asynchronous 48 V
1450 28 kWh
46 kWh
140301000
DriveMaster Ultra 20**
20 kW asynchronous 96 V
1450 56 kWh
92 kWh
140302000
* Supplied capacity.
** With Boost function for easy manoeuvring.
PodMaster series
Mastervolt’s ideal solution for motor or sailyachts is installed under
the hull to save space and minimise sound and vibrations. Sailing
with the PodMaster is the quietest possible solution for electric sailing.
The PodMaster is made of seawater-proof aluminium and given six
layers of epoxy coating for extra protection. Depending on the model,
the bulb contains an ultra-modern, sensor-free, 3-phase permanent
magnet synchronised motor or a highly efficient permanent magnet
DC motor. The motor, bearings and plugs were designed for
professional use and guarantee years of sailing enjoyment and
minimum maintenance. Its high capacity and exceptional efficiency
ensure that virtually the entire capacity is transferred to the propeller.
PodMaster
PodMaster Professional series
The PodMaster Professional is the professional low rpm model of our
PodMaster series and fully seawater-proof thanks to its stainless steel
construction. The bulb contains an ultra-modern, sensor-free
permanent magnet 3-stage synchronous motor that was specifically
developed to provide a high torque output. As a result, the PodMaster
Professional can be used with a large diameter propeller for extra
efficient propulsion.
PodMaster Steerable
PodMaster Professional
Specifications on following page
