2.5 Waterproof Wiper Motor
• Fully sealed powder coated aluminum waterproof base
and housing
• Powers a 26" Deluxe arm and Deluxe blade combination
or a 24" Premier arm and Premier blade combination
• Available in two shaft lengths: 1.5" and 2.5"
(includes .5" length of knurled arm fitting)
• Factory pre-set sweep angles of 80° or 110°, with easy
adjustment to 45° or 60°
• Chrome plated solid brass knurled drive nut with brass
and stainless steel drive shaft
• Two speed motor
• Sealed 6" wire leads, 16 AWG
• Adjustable right or left self parking
• .625" diameter shaft (16 mm)
• Available in 12V and 24V models
• Coast to park
• RF shielded circuitry
• Retail version includes 6 amp fuse and holder
(operating switch not included)
• Measures approximately 7.875" L x 4.25" W x 3" D
(see below for detailed dimensional drawings)
• Stall torque: 139 in-lbs (160 kgf/cm; 15.7 Nm)
• Stall current: 9.0–10.5 amps
• No load current: 1.0 -1.6 amps
)
W = 4.25” (108mm)
L = 7.91” (201.0mm)
.26” (6.5mm)
3.13” (79.6mm)
.53” (13.5mm)
D = 3.02” (76.8mm)
.26” (6.5mm)
3.13” (79.6mm)
Voltage Sweep Item #
OEM #
1.5" Shaft
12V 80°
82081
82181
2.5" Shaft
12V 80°
82082
82182
12V 110°
82012
—
24V 110°
82312
82212
Accessories:
Wiper Motors
