1000 Waterproof Wiper Motor
• Powers 18" Deluxe arm and 18" Deluxe blade combination
at sweep sets of 80° or less
• Powers 16" Deluxe arm and 16" Deluxe blade combinations
at a sweep set of 110°
• Factory pre-set sweep of 80° or 110° adjustable to
50°, 65°, 80°, or 110°
• .625" diameter shaft (16 mm )
• Fully sealed waterproof housing made of UV stabilized,
high-temperature, high-impact thermoplastic
• 12 volt heavy-duty motor with anti-rotation drive shaft
• Knurled drive shaft and solid brass arm drive nut
• Coast to park with adjustable right or left self parking
• Retail version includes 5 amp fuse and holder
(on/off switch not included)
• RF shielded circuitry
• Weight: 1.75 lbs
• Available in two shaft lengths: 1.5" and 2.5"
(includes .5" length of knurled arm fitting)
• Measures approximately 6.625" L x 3.375"W x 2" D
• Stall torque: 55 in-lbs (63 kgf/cm; 6.2 Nm)
• Stall current: 9.8–10.0 amps
• No load current: 0.8–1.2 amps
)
L = 6.63” (168.4mm)
W = 3.3” (83.8mm)
2.35” (59.69mm)
.20” (5mm)
.5” (12.7mm)
D = 2.0” (50.8mm)
2.35” (59.69mm)
Voltage Sweep Item#
OEM #
1.5" Shaft
12V 65°
— 36161
80°
36180
36181
110°
36110
36111
2.5" Shaft
12V 65°
— 37161
80°
37180
37181
110°
37110
37111
2.5" Shaft
Kits
12V 80°
37100
—
110°
37200
—
