Accessories
|
Wiper Systems
Accessories:
Wiper Motors
Heavy Duty Plus 3.0 Motor
The Heavy Duty Plus 3.0 Motor is Marinco's only external
linkage motor. This design easily powers a 30" Premier arm
and 30" Premier blade combination to provide coverage up to
45" of windshield area.
• Available in two shaft lengths: 2.5" and 3.5"
(knurled arm fitting adds 2" to overall length)
• Tapered knurled drive shaft
• Factory pre-set sweep angle of 110°, with easy adjustment
to 45° or 60°
• Sealed 6" wire leads, 16 AWG
• For interior installations
• Adjustable right or left self parking
• 18 mm diameter shaft
• Measures approximately 8.5" L x 4.625" W x 4.375" D
(See below for detailed dimensional drawings)
• Stall torque: 165 in-lbs (190 kgf/cm; 18.6 Nm)
• Stall current: 12.5–14.5 amps
• No load current: 0.8–2.0 amps
• Recommended fuse: 6 amp fuse
• Available in 12V and 24V models
• Coast to park
• RF shielded circuitry
4.32”(109.9mm)
2.68”(68.3mm)
1.96”(50.0mm)
7.79”(197.9mm)
7.79”(197.9mm)
5.11”(130.0mm)
5.51”(140.0mm)
7.16”(182.0mm)
8.37”(212.8mm)
4.60”(117.0mm)
.25”(6.5mm)
Voltage Sweep
OEM #
2.5" Shaft
12V
110°
73112
3.5" Shaft
12V
110°
73113
24V
110°
73313
