Accessories
|
Wiper Systems
(70.28mm)
L = 7.76” (197.0mm)
W = 3.98” (101.0mm)
2.87” (73.0mm)
.20” (5mm)
.53” (13.5mm)
D = 2.77” (70.28mm)
2.87” (73.0mm)
.20” (5mm)
1.5 Waterproof Wiper Motor
• Fully sealed powder coated aluminum waterproof base
and housing
• Powers a 22" Deluxe arm and 22" Deluxe blade combination
or a 20" Premier arm and 20" Premier blade combination
• Available in three shaft lengths: 1.5" and 2.5"
(includes .5" length of knurled arm fitting)
• Factory pre-set sweep angles of 80° or 110°, with easy
adjustment to 45° or 60°
• Chrome plated solid brass knurled drive nut with brass
and stainless steel drive shaft
• Two speed motor
• Sealed 6" wire leads, 16 AWG
• Adjustable right or left self parking
• .625" diameter shaft (16 mm)
• Available in 12V and 24V models
• Coast to park
• RF shielded circuitry
• Retail version includes 5 amp fuse and holder
(operating switch not included)
• Measures approximately 7.75" L x 4" W x 2.75" D
(see below for detailed dimensional drawings)
• Stall torque: 109 in-lbs (125 kgf/cm; 12.3 Nm)
• Stall current: 11.5–13.0 amps
• No load current: 0.5–1.2 amps
• Replaces AFI 2000 motor
Voltage Sweep Item # OEM #
1.5" Shaft 12V 80° 71081 —
12V 110° 71011 —
2.5" Shaft 12V 80° 71082 71182
12V 110° 71012 71112
Accessories: Wiper Motors
