hubbell-acmeelectric.comC o n s t a n t V o l t a g e R e g u l a t o r s
Acme True-Power
®
products consist of speciality designed ferroresonant transformers. Although ferroresonant transformers have been
an economical solution to power problems for many years, it took the skills of Acme’s highly regarded engineering staff to refine it to meet
today’s exacting requirements.
For example, typical ferroresonant transformers have an input limited to 100 -130 V. Acme’s True -Power
®
units have an input range of
+10/-20% around input voltage nominals of 120/208/240 and 480 volts. At 120 volt input, this relates to 95-130 volts.
The typical ferroresonant transformer has limited electrical noise suppression capability. True-Power
®
power line conditioners have the
following noise attenuation capability:
Common Mode: 120 db
Transverse Mode: 60 db
The typical ferroresonant transformer has an audible hum that can be objectionable in most offices. Acme’s True-Power
®
power line
conditioners are encapsulated in epoxy to lower sound levels below ANSI standard C 89.2.
The typical ferroresonant transformer has on output regulation of ± 3% for input line changes only. Acme’s True-Power
®
power line
conditioners have an output regulation of ± 3% for input line and load changes, making them suitable for operation at any load condition.
Features
Q
Reliable, regulated output voltage when input voltage varies, even to brownout levels.
Q
Extended operation to 65% of nominal when operated at 60% of full load.
Q
Noise rejection—effectively suppressing transient spikes and surges—120 db common mode and 60 db transverse mode.
Q
Rapid response to line and load changes—5% variation in 8m sec, 10% variation in 16m sec.
Q
Hold up time of 3m sec for complete loss of input power.
Q
Inherent overload and short circuit protection, without thermo protectors, fuses or circuit breakers, for immediate recovery when
the overload is removed.
Q
Sinusoidal output features, less than 3% harmonic distortion, improves input wave forms which have total harmonic distortions of
greater than 5%.
Q
Available in 250 through 15,000 VA in hardwired models.
Q
Handle multiple primary input voltages.
Q
Illuminated ON/OFF switch, multiple output receptacles and six foot input power cord on portable units.
Q
UL Listed.
Q
CSA Certified
Applications
Q
Industrial Automation and Control Equipment
Q
Electronic Test Equipment
Q
Robotics
Q
X-Ray Equipment
Q
Communications Equipment
Specifications
Input (Primary)
95-132 VAC (Hardwired)
②
166-228 VAC
192-264 VAC
384-528 VAC
Phase:
1 Phase
②
All hardwired models will accommodate these primary
input voltages
.
Specifications
Output (Secondary)
120/208/240 VAC (Hardwire)
Load Range
0-100%
Regulation
± 3% for line/load changes
Attenuation
120 db Common Mode Noise
60 db Transverse Mode Noise
Audible Noise
Below ANSI std. C 89.2
