toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comC o n s t a n t V o l t a g e R e g u l a t o r s
Product Selection Guide
Problem Encountered
Shielded Isolation Transformer
True-Power
SPS
UPS
Power Failure
—
—
X
X
Widely Varying Source Voltage
—
X
—
X
Brown Outs
—
X
X
X
Switching Of Power Factor Correction Capacitors
X
X
X
X
Distorted Wave Shape Due To Harmonic Content
—
X
—
X
Common-Mode Transients
X
X
—
X
Transverse-Mode Transients
—
X
X
X
Voltage Spikes Due To Proximity Of
Welding Equipment Or Certain
Medical Diagnostic Equipment
X
X
X
X
Line Distortion Due To Noise Generated
From Occasional Lightning Strikes
X
X
X
X
Operation Of Computer Storage Devices Such
As Floppy Disks Or Winchester Drives
Generates Transients
X
X
X
X
HARDWIRED MODELS — CONSTANT VOLTAGE REGULATORS
95-132 X 166-228 X 192-264 X 384-528 VOLT PRIMARY — 120/208/240 VOLT SECONDARY — 1Ø, 60 Hz
APPROXIMATE DIMENSIONS
(Inches)(Cm.)
}
kVA
Size
Catalog
Number
A
B
C D E
F
G
H
J Mounting Type
(Wall)(Floor)
Weight
(Lbs.)(Kg.)
Figure
Wiring
Diagrams
0.25 T169430 15.50 6.30 5.80 5.63 8.13 9.30 1.2 .41 x .81 5.00
F&W
37
II
16
(39.4)
(16.0)
(14.7)
(14.3)
(20.7)
(23.6)
(3.0)
(1.0 x 2.1)
(12.7)
(16.8)
0.35 T169431 17.00 7.00 7.30 5.63 8.13 9.40 2.3 .41 x .81 6.50
F&W
51
II
16
(43.2)
(17.8)
(18.5)
(14.3)
(20.7)
(23.9)
(5.8)
(1.0 x 2.1)
(16.5)
(23.1)
0.50 T169432 17.00 7.00 7.30 5.63 8.13 9.40 2.3 .41 x .81 6.50
F&W
53
II
16
(43.2)
(17.8)
(18.5)
(14.3)
(20.7)
(23.9)
(5.8)
(1.0 x 2.1)
(16.5)
(24.0)
0.75 T169433 17.00 7.00 7.30 5.63 8.13 9.40 2.3 .41 x .81 6.50
F&W
65
II
16
(43.2)
(17.8)
(18.5)
(14.3)
(20.7)
(23.9)
(5.8)
(1.0 x 2.1)
(16.5)
(29.5)
1.00 T169434 18.50 6.50 8.55 5.63 8.13 9.50 2.3 .41 x .81 7.75
F&W
82
II
16
(47.0)
(16.5)
(21.7)
(14.3)
(20.7)
(24.1)
(5.8)
(1.0 x 2.1)
(19.7)
(37.2)
2.00 T169435 19.00 10.50 10.20 6.00 12.00 13.25 2.3 .44 x .63 9.40
F&W
142
III
16
(48.3)
(26.7)
(25.9)
(15.2)
(30.5)
(33.7)
(5.8)
(1.1 x 1.6)
(23.9)
(64.4)
3.00 T169436 19.00 10.50 10.20 6.00 12.00 13.25 2.3 .44 x .63 9.40
F&W
176
III
16
(48.3)
(26.7)
(25.9)
(15.2)
(30.5)
(33.7)
(5.8)
(1.1 x 1.6)
(23.9)
(79.8)
5.00 T169437 22.00 12.54 12.20 6.00 14.00 15.25 2.3 .44 x .63 11.40
F&W
295
III
16
(55.9)
(31.9)
(31.0)
(15.2)
(35.6)
(38.7)
(5.8)
(1.1 x 1.6)
(29.0)
(134.0)
10.00 T169438 23.06 27.31 24.06 18.00 25.50 — — .56
— F&W
①
605
IV
16
(58.6)
(69.4)
(61.1)
(45.7)
(64.8)
(1.4)
(274.0)
15.00 T169439 23.06 40.13 24.06 18.00 38.31 — — .56
—
F
880
IV
16
(58.6)
(101.9)
(61.1)
(45.7)
(97.3)
(1.4)
(399.0)
①
Wall mounting brackets required for this size. Refer to Page 217.
}
Dimensions not suitable for construction. Contact factory.
All Wiring Diagrams begin on page 209.
