Bus Bars
• Now with easy-fit covers to ABYC standards, with polarity ID
• 5/32" (4 mm) stainless steel screws with shakeproof washers
• 2 x 1/4" (6 mm) input studs
• Tin-plated, brass-insulated mounting bases with recessed
mounting holes to avoid accidental shorts on aluminum surfaces
• Supplied standard with all BEP™ AC & DC control panels
• Display pack versions supplied with cover
Item #
OEM #
Bus
Type
Output
screws
Input
studs
Rating
(A)
BB-6W-2S/DSP
BB-6W-2S Single 6
2
100
BB-12W-2S/DSP
BB-12W-2S Single 12
2
100
BB-24W-2S/DSP
BB-24W-2S Single 24
2
150
BB-12W-2NC/DSP
BB-12W-2NC Double 2 x 12 2 x12 way 100
BB-4S-150A/DSP
BB-4S-150 4-way 1 x 4 4 x 6 mm
(1/4 stud)
150
6 W
Item #
Description
BBC-6WR
Positive
BBC-6WBK
Negative
12 W
Item #
Description
BBC-12WR
Positive
BBC-12WBK
Negative
24 W
Item #
Description
BBC-24WR
Positive
BBC-24WBK
Negative
Item #
Description
TB-118-6P
6 connections
TB-118-10P
10 connections
Bus Bar Covers
• Flame-resistant flexible plastic
• Color-coded for polarity
• Unique push-on fit
• Supplied standard with bus bars when ordered
in display packs (for bulk packaging ordered
separately)
5.4"x1.4"x1.1"
138x35x29 mm
BB-4S-150A/DSP
4.6"x0.6"x1.1"
117x15x29 mm
BB-6W-2S
7"x0.6"x1.1"
177x15x29 mm
BB-12W-2S
8"x0.9"x1.1"
204x24x29 mm
BB-24W-2S
6.8"x1.7"x1.1"
173x42x29 mm
BB-12W-2NC
Manage:
Battery Distribution Accessories
Manage
|
Distribution Components
Terminal Blocks
Ideal for isolated connections up to 30A. Suitable
for connecting tails from AC and DC panels.
Base material: Phenolic; Current rating 30A; Max.
voltage rating: 300V AC/DC; Screw size: 0.25"
(6.3 mm)
