Terminal Links
The 708 links are designed for space saving interconnections
of terminals when battery distribution modules are linked
together. Four standard solid links are available for
interconnection of the 701 battery switch with other Battery
Distribution products and two larger links which are intended
for the heavy-duty battery switch.
19 mm
Suits 701
708-42.5
25 mm
Suits 720
708-62.0
Item #
Distance
between centers Hole diameter
708-42.5
1.7"
43 mm 3/8"
10 mm
708-54.5
2.2"
55 mm 3/8"
10 mm
708-64.5
2.6"
65 mm 3/8"
10 mm
708-68.5
2.7"
69 mm 3/8"
10 mm
708-62.0
2.45"
62 mm 1/2"
12 mm
Four Way Distribution Stud
The 704-4S was designed for multiple
heavy-duty connections which
need to be isolated from each
other. This model completes the
range of heavy-duty connectors
and meets ABYC standards for
exposed terminals.
Dual Distribution Stud
Designed specifically for transom
areas for connecting battery cables
from outboards. It also has many
other applications where heavy-duty
positive and negative connections
need to be terminated.
Secondary Bus
Fitted to Distribution Stud 702 allows for small wire connections
without cluttering main stud. Terminal screws 1/8" (4 mm).
Item # 702SB
The patented Contour Locking System is an innovative feature that allows for multiple battery management components to
be connected to each other providing for a clean finished installation. These locking tabs can be found on battery switches,
heavy-duty buss bars, fuse holders, distribution studs and breaker modules.
Distribution Stud
The Contour Distribution Stud allows
terminating of heavy-duty cables for
one or more connections. Contour
Lock housing has removable side
plates which allows for connections
from all sides.
Manage:
Battery Distribution Accessories
Description
Stud Size
OEM #
LxWxH
Distribution Stud
10 mm, 3/8"
702B
2.75"x2.75"x2" 69x69x50 mm
Dual Distribution Stud
2 x (10 mm, 3/8")
702-2S/B
2.75"x2.75"x2" 69x69x50 mm
1 x (8 mm, 5/16")
1 mm x (10 mm, 3/8")
702-8-10-B 2.75"x2.75"x2" 69x69x50 mm
Dual Distribution Stud
with Link Plate
2 x (10 mm, 3/8")
702-2SB/L
2.75"x2.75"x2" 69x69x50 mm
Four Way Distribution Stud 4 x (10 mm, 3/8")
704-4S/B
5.3"x2.75"x2"
138x69x50 mm
702B
702-2SB
704-4S/B
