Mastervolt transfer systems:
Regulates 120V & 230V power sources
The Mastervolt transfer system helps you regulate your shore,
generator or inverter power and automatically selects the right power
sources at the right time. With Mastervolt you can cook and do laundry
at the same time or watch TV with the airco on full blast. In addition,
Mastervolt transfer systems are suitable for every installation.
Masterswitch: The simple solution
• Two AC inputs, for example grid power and generator.
• One outlet to AC power group.
• Automatic switching.
• Power transfer up to 25 kW, input/output from 20–125A.
• Can be combined with circuit breakers (Masterswitch Fuses).
Mass Systemswitch: The complete system solution
• Three AC inputs, for example inverter, grid power and generator.
• Three or four outlets to 230V power groups.
• Automatic switching.
• Power transfer from 4.5–16 kW, input/output from 25–63A.
• Information source for central energy management via
MasterBus network.
• Optional automatic fuses; for larger systems this usually requires
an extra casing.
• MasterBus compatible.
The Mastervolt transfer system controls the following:
• Activating and selecting 230V sources: Shore power, inverter
and generator (adjustable to amperage of shore power, for
instance 6A).
• Prevents damaging contact between the inverter and other
230V sources.
• Fully compatible with Mastervolt systems, and suitable for
installations from other brands, other generators and/or inverters.
Manage:
Transfer Systems
