Manage
|
Distribution Components
Item #
OEM #
Rating (A)
in
LxWxH
mm
LxWxH
Stud Size
707
—
1 x 50A, 2 x 25A 5.4"x2.71"x3"
138x69x75 mm 3/16"
5 mm
706-4W
706-4WB
1 x 5A, 3 x 15A 5.4"x2.71"x3"
138x69x75 mm 5/32"
4 mm
706-2W
—
2x10A
2.71"x2.71"x2.75 69x69x70 mm 5/32"
4 mm
Circuit Breaker Module
Provides 3 CBs ideal for medium duty loads, like waste
treatment systems and electric toilets. Designed to separate
these loadings from the main DC panel, avoiding voltage
spikes. Supplied standard with 1 x 50A and 2 x 25A B Series
CBs in a Contour Lock housing for easy modulation. Extra CBs
available (page130).
Labels ordered separately: SET-714.
Item # 707
24hr Service Circuit Breaker Module (4W)
Consists of one 5A and three 15A push to reset Carling CLB
Series thermal CBs. Suitable for essential circuits such as bilge
pump, auto float switch supplies and stereo memory circuits.
The push to reset function ensures essential 24hr circuits
cannot be switched off inadvertently. This is contained in the
contour lock double module. For spare circuit breakers see 131.
Labels: SET-714
Item # 706-4W
OEM # 706-4WB
24hr Essential Circuit Module
Designed for smaller systems where only 2 circuit breakers
are required. Supplied with 2 x 10A Carling CLB Series circuit
breakers – push to reset.
Item # 706-2W
