Fully Integrated CZone™ & MasterBus System
Advantages of one system:
• Fewer cables
• Less weight
• Installation time savings
• Remotely accessible
• Easy to maintain
• Integrated solution
TM
1
Ultrasonic tank sender
2
Switch cluster
3
Signal Interface
4
Switch Control Interface
5
CZone MasterBus Bridge
Interface
6
NMEA T-connector
7
10" Touch screen
8
Meter Interface
9
Output Interface
10
Wireless Interface
11
Battery distribution panel
NMEA 2000 network
DC loads
• Single button ‘mode’ selection
• Redundant and safe
• Global service network
• Increased flexibility in terms of design changes
• ‘Super Yacht’ power and load management capabilities
