Manage
|
MasterBus
MasterView Easy
Touchscreen control panel for all MasterBus products
This touchscreen control panel is easy to read and operate. The grey button turns
the display on or off or locks it, while all other functions can be controlled using the
touchscreen. The first of three control levels provides a short system overview with
all the information you may need on a daily basis. The product overview screen
shows detailed information. The favourites screen can be custom designed to
meet your specific needs for information and control. The MasterBus cable is used
for data transfer and as a power supply for the display.
Benefits:
• Clearly lit display.
• On/off button and lock to prevent unwanted activities.
• Touchscreen control of all functions.
• White background light – red for alarm functions or night lighting.
• Buzzer and alarm function.
• Requires only one MasterBus cable for data transfer and power supply.
• Low energy consumption.
• Easy to install (Flush and surface mounted).
Manage:
MasterBus Panels
MasterView Read-out
Remote panel for reading the charge status of your battery charger,
including error notifications.
Item #
77010050
Display
7 LEDs
Dimensions (HxW)
2.4"x2"x6" / 60x65 mm
MasterBus connection yes
Powered by
MasterBus
Power consumption
144 mW
Protection degree
IP21
Weight
0.15 lbs / 70 gr
Item #
77010305
Display
3.5" touch screen
Dimensions (HxWxD)
4.3"x4.3"x0.8" / 110x110x20 mm
MasterBus connection yes
Powered by
MasterBus
Power consumption
160 mW
Protection degree
IP21
Weight
0.51 lbs / 230 gr
Languages
ENG, NL, DE, SP, IT, FRA, FIN, SWE, DEN, NOR
MasterView Read-out OEM
If your dashboard is full and does not offer space for a MasterView panel, this module
allows you to integrate the MasterBus Read-out into your own control panel.
Item # 77010030
