DC Distribution 500
Item #
77020200
Dimensions (HxWxD) 5.9"x7.9"x2.5" / 150x216x65 mm
Weight
2.6 lbs / 1.2 kg
Battery voltage
12, 24 or 48V DC
Current
300A continuous / 500A for 5 minutes
MasterBus powering no
Standard fuses
80, 80, 125, 160A - ANL type
(deviating values can be ordered separately)
Spare fuse
125A ANL type
Alarm
fuse monitoring
Protection degree
IP21
Delivered with
5 fuses, hex tool, MasterBus Terminator, MasterBus cable,
cable protections for DC connections
Manage
|
MasterBus
DC Distribution 500
The DC Distribution 500 is the smallest distribution model available. It connects up to four
DC devices to the DC groups, such as a battery charger, inverter, alternators and solar
panels. With the included plug & play cable it can be easily connected to the MasterBus
network. The MasterView panel gives all fuses logical names, for instance, referring to the
connected equipment, to ensure you receive understandable error notifications (for
example: battery charger fuse defect).
