PRIMARY VOLTAGE — 120V 60Hz
Part Number
Nominal Power
(VA)
Secondary Voltage
(Volts)
Secondary Current
(Amps)
Core Loss
(Watts)
Copper Loss
(Watts)
OD x H
Inches (mm)
Weight
Lbs. (kg)
Mounting
Hardware
AA50182009
18
2 x 9
1.0
3.0
0.20
2.5 x 1.3 (64 x 33)
0.7 (0.3)
#8
AA50182012
2 x 12
0.7
3.0
0.20
AA50182015
2 x 15
0.6
3.0
0.20
AA50182018
2 x 18
0.5
3.0
0.20
AA50362009
36
2 x 9
2.0
5.8
0.25
2.9 x 1.5 (74 x 38)
1.1 (0.5)
#10
AA50362012
2 x 12
1.5
5.8
0.25
AA50362015
2 x 15
1.2
5.8
0.25
AA50362018
2 x 18
1.0
5.8
0.25
AA50602009
60
2 x 9
3.3
8.6
0.45
3.3 x 1.4 (84 x 36)
1.6 (0.7)
#10
AA50602012
2 x 12
2.5
8.6
0.45
AA50602015
2 x 15
2.0
8.6
0.45
AA50602018
2 x 18
1.7
8.6
0.45
AA50902012
90
2 x 12
3.8
12.0
0.60
3.7 x 1.5 (94 x 38)
1.9 (0.9)
#10
AA50902015
2 x 15
3.0
12.0
0.60
AA50902018
2 x 18
2.5
12.0
0.60
AA50902022
2 x 22
2.0
12.0
0.60
AA51152012
115
2 x 12
4.8
16.0
0.90
3.9 x 1.5 (99 x 38)
2.2 (1)
1/4"
AA51152015
2 x 15
3.8
16.0
0.90
AA51152018
2 x 18
3.2
16.0
0.90
AA51152022
2 x 22
2.6
16.0
0.90
AA51702012
170
2 x 12
7.1
19.0
1.20
3.9 x 1.9 (99 x 48)
3.1 (1.4)
1/4"
AA51702015
2 x 15
5.7
19.0
1.20
AA51702018
2 x 18
4.7
19.0
1.20
AA51702022
2 x 22
3.9
19.0
1.20
AA52201220
220
220
1.0
20.0
1.40
4.5 x 1.8 (114
x 46)
4 (1.8)
1/4"
AA52202018
2 x 18
6.1
20.0
1.40
AA52202022
2 x 22
5.0
20.0
1.40
AA52202024
2 x 24
4.6
20.0
1.40
AA53601220
360
220
1.6
22.0
1.70
4.5 x 2.4 (114
x 61)
5.4 (2.5)
1/4"
AA53602024
2 x 24
7.5
22.0
1.70
AA53602030
2 x 30
6.0
22.0
1.70
AA53602033
2 x 33
5.5
22.0
1.70
AA53602038
2 x 38
4.7
22.0
1.70
AA54501220
450
220
2.1
27.0
2.00
5.4 x 2 (137 x 51)
6.5 (3)
1/4"
AA54502030
2 x 30
7.5
27.0
2.00
AA54502033
2 x 33
6.8
27.0
2.00
AA54502038
2 x 38
5.9
27.0
2.00
