PRIMARY VOLTAGE — 120V 60Hz (CONT.)
Part Number
Nominal Power
(VA)
Secondary Voltage
(Volts)
Secondary Current
(Amps)
Core Loss
(Watts)
Copper Loss
(Watts)
OD x H
Inches (mm)
Weight
Lbs. (kg)
Mounting
Hardware
AA55501220
550
220
2.5
31.0
2.40
5.4 x 2.6 (137 x 66)
8.5 (3.7)
1/4"
AA55502030
2 x 30
9.2
31.0
2.40
AA55502033
2 x 33
8.3
31.0
2.40
AA55502038
2 x 38
7.2
31.0
2.40
AA56501120
650
120
5.4
36.0
3.10
5.4 x 2.8 (137 x 71)
9.5 (4.3)
5/16"
AA56502024
2 x 24
13.5
36.0
3.10
AA56502030
2 x 30
10.8
36.0
3.10
AA56502042
2 x 42
7.7
36.0
3.10
AA57901120
790
120
6.6
45.0
3.80
5.8 x 2.8 (147 x 71)
11.5 (5.2)
5/16"
AA57902024
2 x 24
16.5
45.0
3.80
AA57902030
2 x 30
13.2
45.0
3.80
AA57902042
2 x 42
9.4
45.0
3.80
AA50001120
1000
120
8.3
45.0
3.80
6.5 x 2.6 (165 x 66)
12.4 (5.6)
5/16"
AA50002024
2 x 24
20.8
45.0
3.80
AA50002030
2 x 30
16.7
45.0
3.80
AA50002042
2 x 42
11.9
45.0
3.80
Note:
Electrical measurements @ 20°C ambient temperature. All data subject to change without prior notice.
TOROIDAL TRANSFORMER – INTERNATIONAL VOLTAGE 2x117V, 50/60Hz
Features
Q
2 x 117V/50-60Hz primaries
Q
Many popular secondary voltage options
Q
15 to 990VA ratings available
Q
Listed as recognized/certified components (UL and CSA)
Q
Class A (105°C)
Q
Disk mounting hardware included
Q
10” color coded self leads
Q
Wiring configurations with color codes
PRIMARY VOLTAGE — 2 X 117V 50/60 Hz
Part Number
Nominal Power
(VA)
Secondary Voltage
(Volts)
Secondary Current
(Amps)
Core Loss
(Watts)
Copper Loss
(Watts)
OD x H
Inches (mm)
Weight
Lbs. (kg)
Mounting
Hardware
AA50152006
15
2 x 6
1.25
3.0
0.20
2.5 x 1.3 (64 x 33)
0.7 (0.3)
#8
AA50152009
2 x 9
0.83
3.0
0.20
AA50152012
2 x 12
0.62
3.0
0.20
AA50152015
2 x 15
0.5
3.0
0.20
AA50152018
2 x 18
0.42
3.0
0.20
AA50152022
2 x 22
0.3
3.0
0.20
AA50302006
30
2 x 6
2.5
5.8
0.25
3.0 x 1.5 (76 x 38)
1.1 (0.5)
#10
AA50302009
2 x 9
1.67
5.8
0.25
AA50302012
2 x 12
1.25
5.8
0.25
AA50302015
2 x 15
1
5.8
0.25
AA50302018
2 x 18
0.88
5.8
0.25
AA50302022
2 x 22
0.68
5.8
0.25
